SCHAEFFLER C002-01S0 Series Sensor Box, 4 Port, Ethernet, PROFINET, Fieldbus, USB

RS 제품 번호:: 311-607
제조사 부품 번호:: SENSOR-C002-01S0-00MILM8
제조업체:: SCHAEFFLER

SCHAEFFLER C002-01S0 Series Sensor Box, 4 Port, Ethernet, PROFINET, Fieldbus, USB

Subtotal (1 unit)*

₩1,494,368.85

추가로 2026년 6월 18일 부터 4 개 단위 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩1,494,368.85

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 311-607
제조사 부품 번호:: SENSOR-C002-01S0-00MILM8
제조업체:: SCHAEFFLER

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	SCHAEFFLER
	Product Type	Sensor Box
	Number of Ports	4
	Maximum Operating Voltage	30V dc
	Series	C002-01S0
	Interface Type	Ethernet, PROFINET, Fieldbus, USB
	IP Rating	IP20
	Minimum Operating Temperature	-30°C
	Maximum Operating Temperature	60°C
	Standards/Approvals	RoHS, UL, CE, EAC, CSA, UKCA
	Output Type	Digital
	Minimum Operating Voltage	18V

	모두 선택
	브랜드 SCHAEFFLER
	Product Type Sensor Box
	Number of Ports 4
	Maximum Operating Voltage 30V dc
	Series C002-01S0
	Interface Type Ethernet, PROFINET, Fieldbus, USB
	IP Rating IP20
	Minimum Operating Temperature -30°C
	Maximum Operating Temperature 60°C
	Standards/Approvals RoHS, UL, CE, EAC, CSA, UKCA
	Output Type Digital
	Minimum Operating Voltage 18V

Datasheet - SENSOR-C002-01S0-00MILM8

SCHAEFFLER C002-01S0 Series Sensor Box, Ethernet Interface, IP20 - SENSOR-C002-01S0-00MILM8

This sensor box provides a Compact Interface for connecting field sensors to industrial networks and host systems. It enables digital signal aggregation and communication over Ethernet, PROFINET, Fieldbus and USB in automation environments, supporting common industrial voltage ranges and a wide ambient temperature span for varied plant conditions.

Features and Benefits:

• IP20 enclosure for protected indoor installation • Operates between -30°C and 60°C for broad ambient ranges • Accepts 18-30V DC supply for common industrial power rails • Four‑port design to consolidate multiple sensor connections • Digital output signalling to integrate with control systems • Conforms to RoHS, UL, CE, EAC, CSA and UKCA for regulatory fit

Applications

• Suitable for distributed I/O nodes in factory automation • Ideal for PROFINET Ethernet sensor box IP20 deployments • Used for machine‑level sensor consolidation with 4 ports • Can be used for Fieldbus, USB and digital‑output sensor module setups • Used with industrial control systems requiring 18-30V DC operation

Which connector style is compatible with the cabling infrastructure?

It uses an MIL M8 connector format to match standard circular sensor cabling.

What approvals indicate regulatory acceptance for industrial sites?

The unit carries multiple approvals including RoHS, UL, CE, EAC, CSA and UKCA.

How many interfaces are available for network and host connections?

It provides Ethernet, PROFINET, Fieldbus and USB interfaces for flexible networking.

What type of signalling does the module provide to controllers?

The device offers digital outputs suitable for binary sensor states and discrete signals.
