Eaton ES4P Series Safety Controller, 14 Safety Inputs, 8 Safety Outputs, 24V dc
- RS 제품 번호:
- 814-0383
- 제조사 부품 번호:
- 111018 ES4P-221-DRXX1
- 제조업체:
- Eaton
Subtotal (1 unit)*
₩1,890,372.90
현재 액세스할 수 없는 재고 정보 - 나중에 다시 확인해 주세요.
수량 | 한팩당 |
|---|---|
| 1 + | ₩1,890,372.90 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 814-0383
- 제조사 부품 번호:
- 111018 ES4P-221-DRXX1
- 제조업체:
- Eaton
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Eaton | |
| Product Type | Safety Controller | |
| Series | ES4P | |
| Number of Safety Inputs | 14 | |
| Number of Safety Outputs | 8 | |
| Safety Category | 4 | |
| Mount Type | DIN Rail | |
| Field Bus Communication Type | Profibus, CAN Open | |
| Expansion Available | Yes | |
| Supply Voltage | 24V dc | |
| Number of I/Os | 18 | |
| Contact Current | 6A | |
| Contact Voltage | 250V | |
| Standards/Approvals | IEC, UL, CSA, CE | |
| Terminal Type | Screw | |
| IP Rating | IP20 | |
| 모두 선택 | ||
|---|---|---|
브랜드 Eaton | ||
Product Type Safety Controller | ||
Series ES4P | ||
Number of Safety Inputs 14 | ||
Number of Safety Outputs 8 | ||
Safety Category 4 | ||
Mount Type DIN Rail | ||
Field Bus Communication Type Profibus, CAN Open | ||
Expansion Available Yes | ||
Supply Voltage 24V dc | ||
Number of I/Os 18 | ||
Contact Current 6A | ||
Contact Voltage 250V | ||
Standards/Approvals IEC, UL, CSA, CE | ||
Terminal Type Screw | ||
IP Rating IP20 | ||
제외
Eaton easySafety ES4P Controller
The easySafety ES4P safety control relay monitors and evaluates safety-related information from safety devices such as position switches, light curtains, two-hand controls and emergency-stop buttons. The simple operation and variable configuration of the safety and control functions guarantee quick error diagnostics with the installation and machine components. Safety applications can be implemented that comply with international safety standards, such as category 4 in accordance with EN 954-1, PL e in accordance with EN ISO 13849-1, SILCL 3 in accordance with EN IEC 62061 and SIL 3 in accordance with EN IEC 61508.
There are two version available, a rugged version with relay outputs for safety and standard tasks (stock nos. 814-0389 & 814-0383) and a versatile version with transistor outputs and also one redundant relay output for flexible safety and standard tasks (stock nos. 814-0377 & 814-0386). Configuration is undertaken either directly on the device or on the PC using the easySoft-Safety software. It is possible to select between stand alone or integrated solutions in the easyNet network.
14 safety inputs
4 safety relay outputs (stock nos. 814-0389 & 814-0383)
4 safety transistor outputs and 1 redundant safety relay output (stock nos. 814-0377 & 814-0386)
4 test signals
16 operating and message texts
easyLink on board
easyNet on board
Safety and standard circuit diagram
With and without display
Additional remote display connected via integrated RS232 interface
Note
Eaton formerly known as Moeller
Standards
EN 954-1, EN ISO 13849-1, EN IEC 62061, EN IEC 61508.
