- RS 제품 번호:
- 181-2779
- 제조사 부품 번호:
- UG6970.04PS/61 DC24V
- 제조업체:
- Dold
일시 품절-다음 입고 날짜는 04/06/2024 (일/월/년) 이며, 그 후 5-10영업일내 홍콩에서 발송. 정확한 입고 수량에 대한 문의는 krenquiry@rs-components.com 로 연락주세요.
추가완료!
단가 개당
₩767,906.506
수량 | 한팩당 |
1 + | ₩767,906.506 |
- RS 제품 번호:
- 181-2779
- 제조사 부품 번호:
- UG6970.04PS/61 DC24V
- 제조업체:
- Dold
참조 문서
제정법과 컴플라이언스
- COO (Country of Origin):
- DE
제품 세부 사항
Line fault detection on On-button:
Manual restart or automatic restart
With or without cross fault monitoring
2-channel
Forcibly guided output contacts
Output: 2 NO contacts per safety function
1 semiconductor output per safety function
LED indicator for operation, safety function 1, 2 and failure
As option with pluggable terminal blocks for easy exchange of devices
with screw terminals
or with cage clamp terminals
Width: 22.5 mm
Advantages / Customer benefit
2 independent, separately adjustable safety function:
E-Stop
Safety gate
Two-hand control
Safety mat / Safety edge
Exclusive or contacts
Light curtain
Only one device, two safety functions at the same time
Manual or auto start
Protection against manipulation by seal able transparent cover
Manual restart or automatic restart
With or without cross fault monitoring
2-channel
Forcibly guided output contacts
Output: 2 NO contacts per safety function
1 semiconductor output per safety function
LED indicator for operation, safety function 1, 2 and failure
As option with pluggable terminal blocks for easy exchange of devices
with screw terminals
or with cage clamp terminals
Width: 22.5 mm
Advantages / Customer benefit
2 independent, separately adjustable safety function:
E-Stop
Safety gate
Two-hand control
Safety mat / Safety edge
Exclusive or contacts
Light curtain
Only one device, two safety functions at the same time
Manual or auto start
Protection against manipulation by seal able transparent cover
사양
속성 | 값 |
---|---|
Range | Safemaster |
Safety Category | 4, PL e 4, SIL 3 |
Supply Voltage | 24 V dc |
Terminal Type | Screw |
Width | 120.3mm |
Depth | 110mm |
Length | 22.5mm |
