RS PRO 8771854 Series Illuminated Push Button Switch, Momentary, Panel, 30.2 mm Cutout, SPDT, Blue, Green, Red LED, IP67
- RS 제품 번호:
- 877-1854
- 제조업체:
- RS PRO
대량 구매 할인 기용 가능
Subtotal (1 unit)*
₩56,287.20
재고있음
- 추가로 2026년 1월 19일 부터 12 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 - 4 | ₩56,287.20 |
| 5 - 19 | ₩54,614.00 |
| 20 - 49 | ₩52,922.00 |
| 50 - 249 | ₩51,775.20 |
| 250 + | ₩42,619.60 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 877-1854
- 제조업체:
- RS PRO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | RS PRO | |
| Switch Operation | Momentary | |
| Actuator Colour | White | |
| Product Type | Push Button Switch | |
| Illuminated | Yes | |
| Panel Cutout Size | 30.2 mm | |
| Series | 8771854 | |
| Mount Type | Panel | |
| Contact Configuration | SPDT | |
| Terminal Type | Solder Lug/Quick Connect | |
| LED Colour | Blue, Green, Red | |
| IP Rating | IP67 | |
| Actuator Style | Flat | |
| Minimum Operating Temperature | -20°C | |
| Contact AC Voltage | 250V | |
| Maximum Operating Temperature | 55°C | |
| Switch Configuration | On-Mom | |
| Switch Contact Current | 5 A | |
| Standards/Approvals | RoHS | |
| Legend | Power Symbol | |
| 모두 선택 | ||
|---|---|---|
브랜드 RS PRO | ||
Switch Operation Momentary | ||
Actuator Colour White | ||
Product Type Push Button Switch | ||
Illuminated Yes | ||
Panel Cutout Size 30.2 mm | ||
Series 8771854 | ||
Mount Type Panel | ||
Contact Configuration SPDT | ||
Terminal Type Solder Lug/Quick Connect | ||
LED Colour Blue, Green, Red | ||
IP Rating IP67 | ||
Actuator Style Flat | ||
Minimum Operating Temperature -20°C | ||
Contact AC Voltage 250V | ||
Maximum Operating Temperature 55°C | ||
Switch Configuration On-Mom | ||
Switch Contact Current 5 A | ||
Standards/Approvals RoHS | ||
Legend Power Symbol | ||
- COO (Country of Origin):
- TW
Illuminated anti-vandal pushbutton switches Ø 30 mm
The switches feature centre and ring illumination. The non-actuated colours are green (centre) and red (ring), when actuated the ring colour changes to blue and the centre is not illuminated.
Impact resistance: IK03
Bushing Material: Varnished / Polished Stainless Steel
