Molveno SXA4 Series Illuminated Push Button Switch, Latching, Panel, 30 x 22 mm Cutout, DPDT, Red LED, IP54, IP55 250 V
- RS 제품 번호:
- 863-3550
- 제조사 부품 번호:
- SXA4388211000G00
- 제조업체:
- Molveno
대량 구매 할인 기용 가능
Subtotal (1 unit)*
₩6,008.48
재고있음
- 10 개 단위 배송 준비 완료
- 추가로 2026년 3월 24일 부터 100 개 단위 배송
- 추가로 2026년 4월 23일 부터 100 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 - 19 | ₩6,008.48 |
| 20 - 49 | ₩5,828.00 |
| 50 - 99 | ₩5,645.64 |
| 100 - 249 | ₩5,525.32 |
| 250 + | ₩5,406.88 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 863-3550
- 제조사 부품 번호:
- SXA4388211000G00
- 제조업체:
- Molveno
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Molveno | |
| Actuator Colour | Black | |
| Product Type | Push Button Switch | |
| Switch Operation | Latching | |
| Illuminated | Yes | |
| Panel Cutout Size | 30 x 22 mm | |
| Series | SXA4 | |
| Mount Type | Panel | |
| Contact Configuration | DPDT | |
| Terminal Type | Tab | |
| LED Colour | Red | |
| IP Rating | IP54, IP55 | |
| Actuator Style | Button | |
| Contact AC Voltage | 250V ac | |
| Minimum Operating Temperature | -10°C | |
| Maximum Operating Temperature | 120°C | |
| Switch Configuration | On-Off | |
| Standards/Approvals | CSA, UL | |
| Switch Contact Current | 16 A | |
| 모두 선택 | ||
|---|---|---|
브랜드 Molveno | ||
Actuator Colour Black | ||
Product Type Push Button Switch | ||
Switch Operation Latching | ||
Illuminated Yes | ||
Panel Cutout Size 30 x 22 mm | ||
Series SXA4 | ||
Mount Type Panel | ||
Contact Configuration DPDT | ||
Terminal Type Tab | ||
LED Colour Red | ||
IP Rating IP54, IP55 | ||
Actuator Style Button | ||
Contact AC Voltage 250V ac | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature 120°C | ||
Switch Configuration On-Off | ||
Standards/Approvals CSA, UL | ||
Switch Contact Current 16 A | ||
Molveno SXA4 Illuminated Push Button Switch
The SXA4 Water-Resistant Switches are engineered with a square cut-out design (30 x 22 mm), and an ENEC electrical rate that reaches up to 16 A. These switches serve to ensure protection against both water and dust permeation. They showcase integrated dual switches. The SXA4 switches can be used in high-pressure cleaners, ironing steam generators, and other industrial machines and cutters.
Protection degree: IP54
Life: 10000 cycles
Standards
ENEC,
