Schneider Electric Harmony XB6 Series Push Button Switch, Momentary, Panel, 16 mm Cutout, SPDT, Black LED, IP65

모든 Push Button Switches 열람하기

Subtotal (1 unit)*

₩18,123.20

Add to Basket
수량 선택 또는 입력
재고있음
  • 추가로 2026년 1월 19일 부터 85 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량
한팩당
1 +₩18,123.20

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
610-1200
제조사 부품 번호:
XB6EAA21P
제조업체:
Schneider Electric
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Schneider Electric

Product Type

Push Button Switch

Actuator Colour

Black

Switch Operation

Momentary

Illuminated

No

Panel Cutout Size

16 mm

Series

Harmony XB6

Mount Type

Panel

Contact Configuration

SPDT

LED Colour

Black

IP Rating

IP65

Actuator Style

Round

Minimum Operating Temperature

-10°C

Maximum Operating Temperature

55°C

Switch Configuration

1 CO

Standards/Approvals

IEC 60947-5-1CSA C22.2 No 14JIS C 4520UL 508JIS C 852IEC 60947-1

Height

9.0cm

Width

3.0 cm

Length

20cm

Legend

Blank

Schneider Electric Push Button, QuickConnect Terminals, 1.5A Maximum Current Rating - Harmony XB6E Series - XB6EAA21P


Keen to take charge of your industrial equipment? Reach for this Schneider Electric push button. It's a momentary type, so an attached machine is activated when you press the button and is deactivated when you stop pressing. Thanks to its snap-action contacts, the component responds in a flash to give you speedy switching. Finding a spot for it on a busy panel is no problem, thanks to its 16mm cutout size. As it uses QuickConnect terminals, this push button takes the hassle of wiring off your to-do list.

Features & Benefits


• IP65-rated to indicate protection against dust and low-pressure water jets

• Mounts flush to the panel to prevent accidental activation

• Service life of one million cycles, for long-term switching

• Comes pre-assembled, minimising preparation work

• Insulating plastic actuator cuts your exposure to hazardous loads for safe handling

Applications


• Control devices

• Fluid management systems

• Electronics manufacturing

What are snap-action contacts and how do they help my control system?


For responsive panel control, snap-action contacts move independently of the actuator, switching the attached circuit as soon as you apply enough force.

Pushbuttons,Cylindrical Head,Spring Return


Flush cylindrical head

Available with 1NO + 1NC or 2NO + 2NC contacts

Spring return

IP65 protection

Rating 240v ac 1.5A.
