Schneider Electric Harmony 9001K Series Illuminated Push Button Switch, Spring Return, 30 mm Cutout, 1 CO, Black, Blue,
- RS 제품 번호:
- 516-025
- 제조사 부품 번호:
- 9001KR3UH13
- 제조업체:
- Schneider Electric
대량 구매 할인 기용 가능
View bulk pricing optionsSubtotal (1 unit)*
₩164,560.50
재고있음
- 추가로 2026년 6월 01일 부터 8 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 - 4 | ₩164,560.50 |
| 5 - 9 | ₩157,989.00 |
| 10 + | ₩151,671.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 516-025
- 제조사 부품 번호:
- 9001KR3UH13
- 제조업체:
- Schneider Electric
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Schneider Electric | |
| Switch Operation | Spring Return | |
| Product Type | Push Button Switch | |
| Illuminated | Yes | |
| Panel Cutout Size | 30 mm | |
| Series | Harmony 9001K | |
| Contact Configuration | 1 CO | |
| Terminal Type | Screw | |
| LED Colour | Black, Blue, Green, Orange, Red, White, Yellow | |
| IP Rating | IP66 | |
| Minimum Operating Temperature | -25°C | |
| Contact AC Voltage | 240V ac | |
| Contact DC Voltage | 125V dc | |
| Actuator Style | Octagonal | |
| Maximum Operating Temperature | 70°C | |
| Switch Configuration | 1 CO | |
| Height | 45mm | |
| Length | 91.4mm | |
| Standards/Approvals | EU RoHS, REACH, WEEE, RoHS | |
| Width | 48mm | |
| Switch Contact Current | 3A | |
| Legend | Blank | |
| 모두 선택 | ||
|---|---|---|
브랜드 Schneider Electric | ||
Switch Operation Spring Return | ||
Product Type Push Button Switch | ||
Illuminated Yes | ||
Panel Cutout Size 30 mm | ||
Series Harmony 9001K | ||
Contact Configuration 1 CO | ||
Terminal Type Screw | ||
LED Colour Black, Blue, Green, Orange, Red, White, Yellow | ||
IP Rating IP66 | ||
Minimum Operating Temperature -25°C | ||
Contact AC Voltage 240V ac | ||
Contact DC Voltage 125V dc | ||
Actuator Style Octagonal | ||
Maximum Operating Temperature 70°C | ||
Switch Configuration 1 CO | ||
Height 45mm | ||
Length 91.4mm | ||
Standards/Approvals EU RoHS, REACH, WEEE, RoHS | ||
Width 48mm | ||
Switch Contact Current 3A | ||
Legend Blank | ||
- COO (Country of Origin):
- FR
KR 9001 series pulse switch pushbuttons
Supplied with a set of 7 coloured caps (black, green, red, yellow, blue, white and orange) and a contact block.
Spring return mechanism.
This robust range is dedicated to the most extreme environments: petrochemical, automobile, textile, metallurgy, mining industries and airports.
Standards
IEC 60947-1; IEC 60947-5-1; IEC 60947-5-4; EN 60947-5-1; JIS C 4520 and 852; UL 508; CSA C22-2 no. 14
