Phoenix Contact PC 4/3-STF-7.62 Series Pluggable Terminal Block, 3-Contact, 7.62 mm Pitch, 1 Row

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

모든 Pluggable Terminal Blocks 열람하기
대량 구매 할인 기용 가능

Subtotal (1 unit)*

₩6,410.80

Add to Basket
수량 선택 또는 입력
재고있음
  • 추가로 2026년 3월 23일 부터 69 개 단위 배송
  • 추가로 2026년 3월 30일 부터 92 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량
한팩당
1 - 12₩6,410.80
13 - 24₩6,279.20
25 +₩6,147.60

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
803-2796
제조사 부품 번호:
1828252
제조업체:
Phoenix Contact
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Phoenix Contact

Product Type

Pluggable Terminal Block

Number of Contacts

3

Pitch

7.62mm

Current

20A

Number of Rows

1

Minimum Wire Size mm²

2mm²

Housing Material

Polyamide

Connector Gender

Female

Maximum Wire Size mm²

4mm²

Minimum Wire Size AWG

24 AWG

Maximum Wire Size AWG

10 AWG

Orientation

Straight

Colour

Green

Wire Connection Method

Screw

Voltage

630 V

Length

22.84mm

Width

30.7 mm

Series

PC 4/3-STF-7.62

Standards/Approvals

RoHS

Depth

18.1mm

COO (Country of Origin):
DE

Phoenix Contact Power COMBICON PCB Connectors - 7.62mm


These COMBICON connectors from Phoenix contact are brilliant and greatly built PCB connectors. With a universal pitch of 7.62mm to support a huge variety of applications and a screw connection method for a strong and reliable connection, these connectors easily allow you to connect a cable-to-board. Phoenix connections are well-known worldwide so you will easily be able to design these connectors into any design thanks to the connection technologies known design. Not to mention, integrated double steel springs provide additional safety in the event of temperature and power fluctuations, however, having a low-temperature rise thanks to its maximum contact force means this is just a backup safety feature.

Housings are MADE from a strong and Durable green polyamide material with the contacts being Cu (Copper) alloy. All PC connectors in this series feature a 7.62mm, a current rating of 20 A, a cross-section of 4mm² and have a different amount of positions.

Features and benefits:


  • Double steel spring provides extra safety - preventing temperature and power fluctuations

  • Allows connection of two conductors

  • Low-temperature rise, thanks to its maximum contact force

  • Worldwise use thanks to the connection technology

  • Screw connection - reliable hold onto your cable for optimum system reliability

  • PCB Connectors make it effortless connecting to wires to a PCB

    • Applications:


    The PC COMBICON connectors can be used in the below applications, however, are not limited to:

  • Instrumentation

  • Control and measurement

  • Industrial electronics

  • Control wiring

    • How much wire jacket should I strip?


    Phoenix Contact recommends you strip 7mm of wire jacket & any armour for these PCB connectors. Once your cable has been stripped to an appropriate length exposing the bare metal, simply push-in your cable and lock it down with the M3 screw.

    Phoenix Contact COMBICON 7.62mm Two Part Terminal Blocks


    Approvals

    UL94V-0
