Phoenix Contact COMBICON PC Series Pluggable Terminal Block, 2-Contact, 7.62 mm Pitch, 1 Row, 1804797
- RS 제품 번호:
- 325-4698
- 제조사 부품 번호:
- 1804797
- 제조업체:
- Phoenix Contact
대량 구매 할인 기용 가능
Subtotal (1 pack of 5 units)*
₩27,846.00
재고있음
- 추가로 2026년 5월 19일 부터 160 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 | 한팩당* |
|---|---|---|
| 5 - 120 | ₩5,569.20 | ₩27,846.00 |
| 125 - 370 | ₩5,401.50 | ₩27,007.50 |
| 375 - 995 | ₩5,233.80 | ₩26,169.00 |
| 1000 - 1995 | ₩5,093.40 | ₩25,467.00 |
| 2000 + | ₩5,011.50 | ₩25,057.50 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 325-4698
- 제조사 부품 번호:
- 1804797
- 제조업체:
- Phoenix Contact
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Phoenix Contact | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 2 | |
| Pitch | 7.62mm | |
| Number of Rows | 1 | |
| Current | 20A | |
| Housing Material | Polyamide | |
| Maximum Wire Size mm² | 4mm² | |
| Connector Gender | Male | |
| Orientation | Right Angle | |
| Wire Connection Method | Solder | |
| Colour | Green | |
| Voltage | 630V | |
| Series | COMBICON PC | |
| Depth | 19.25mm | |
| Width | 15.22mm | |
| Standards/Approvals | CHINA RoHS, CSA, cULus, EU REACH SVHC, EU RoHS | |
| Length | 29mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Phoenix Contact | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 2 | ||
Pitch 7.62mm | ||
Number of Rows 1 | ||
Current 20A | ||
Housing Material Polyamide | ||
Maximum Wire Size mm² 4mm² | ||
Connector Gender Male | ||
Orientation Right Angle | ||
Wire Connection Method Solder | ||
Colour Green | ||
Voltage 630V | ||
Series COMBICON PC | ||
Depth 19.25mm | ||
Width 15.22mm | ||
Standards/Approvals CHINA RoHS, CSA, cULus, EU REACH SVHC, EU RoHS | ||
Length 29mm | ||
Phoenix Contact COMBICON PC & PCV 4 7.62mm PCB Terminal Block Headers
7.62mm pitch COMBICON PC & PCV 4 series PCB through hole mount terminal block shrouded headers for use with COMBICON PC 4 plugs.
Stock numbers 493-2686 and 803-2777 are horizontal PCB mount (PC Series) the others are vertical PCB mount (PCV Series)
Phoenix Contact COMBICON 7.62mm Two Part Terminal Blocks
Approvals
UL94V-0
