Phoenix Contact DFK-PC 16/6-ST Series Pluggable Terminal Block, 6-Contact, 10.16 mm Pitch, 1 Row, 1703412
- RS 제품 번호:
- 209-8141
- 제조사 부품 번호:
- 1703412
- 제조업체:
- Phoenix Contact
대량 구매 할인 기용 가능
Subtotal (1 pack of 10 units)*
₩379,782.00
일시적 품절
- 2026년 9월 30일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 | 한팩당* |
|---|---|---|
| 10 - 40 | ₩37,978.20 | ₩379,782.00 |
| 50 + | ₩34,179.60 | ₩341,796.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 209-8141
- 제조사 부품 번호:
- 1703412
- 제조업체:
- Phoenix Contact
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Phoenix Contact | |
| Number of Contacts | 6 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 10.16mm | |
| Current | 76A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.75mm² | |
| Housing Material | Polyamide | |
| Maximum Wire Size mm² | 16mm² | |
| Connector Gender | Male | |
| Minimum Wire Size AWG | 18AWG | |
| Maximum Wire Size AWG | 6AWG | |
| Orientation | Horizontal | |
| Colour | Green | |
| Wire Connection Method | Screw Connection with Tension Sleeve | |
| Voltage | 1kV | |
| Width | 80.4mm | |
| Standards/Approvals | No | |
| Length | 56.5mm | |
| Series | DFK-PC 16/6-ST | |
| Depth | 30.55mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Phoenix Contact | ||
Number of Contacts 6 | ||
Product Type Pluggable Terminal Block | ||
Pitch 10.16mm | ||
Current 76A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.75mm² | ||
Housing Material Polyamide | ||
Maximum Wire Size mm² 16mm² | ||
Connector Gender Male | ||
Minimum Wire Size AWG 18AWG | ||
Maximum Wire Size AWG 6AWG | ||
Orientation Horizontal | ||
Colour Green | ||
Wire Connection Method Screw Connection with Tension Sleeve | ||
Voltage 1kV | ||
Width 80.4mm | ||
Standards/Approvals No | ||
Length 56.5mm | ||
Series DFK-PC 16/6-ST | ||
Depth 30.55mm | ||
- COO (Country of Origin):
- PL
The Phoenix Contact feed-through connector with 6 number of positions has screw connection method. It is available in green colour.
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
Flange system enables secure fixing to the housing panel by means of tool-free snap-in locking or screws
