RS PRO CTBP9208 Series Pluggable Terminal Block, 3-Contact, 5.08 mm Pitch, 1 Row
- RS 제품 번호:
- 144-4325
- 제조업체:
- RS PRO
대량 구매 할인 기용 가능
View bulk pricing optionsSubtotal (1 unit)*
₩1,360.00
마지막 RS 재고
- 210 개 단위 배송 준비 완료
- 2026년 7월 24일 부터 최종 39 개 단위 배송
수량 | 한팩당 |
|---|---|
| 1 - 4 | ₩1,360.00 |
| 5 - 19 | ₩1,320.00 |
| 20 - 49 | ₩1,280.00 |
| 50 - 249 | ₩1,260.00 |
| 250 + | ₩1,060.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 144-4325
- 제조업체:
- RS PRO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | RS PRO | |
| Number of Contacts | 3 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 5.08mm | |
| Number of Rows | 1 | |
| Current | 15A | |
| Housing Material | Nylon | |
| Minimum Wire Size AWG | 14AWG | |
| Maximum Wire Size AWG | 28AWG | |
| Orientation | Straight | |
| Colour | Green | |
| Wire Connection Method | Screw | |
| Voltage | 450V | |
| Series | CTBP9208 | |
| Length | 15.2mm | |
| Width | 15.05mm | |
| Depth | 18.1mm | |
| Standards/Approvals | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 RS PRO | ||
Number of Contacts 3 | ||
Product Type Pluggable Terminal Block | ||
Pitch 5.08mm | ||
Number of Rows 1 | ||
Current 15A | ||
Housing Material Nylon | ||
Minimum Wire Size AWG 14AWG | ||
Maximum Wire Size AWG 28AWG | ||
Orientation Straight | ||
Colour Green | ||
Wire Connection Method Screw | ||
Voltage 450V | ||
Series CTBP9208 | ||
Length 15.2mm | ||
Width 15.05mm | ||
Depth 18.1mm | ||
Standards/Approvals No | ||
2-24 pole solid block
Pluggable male-female connectors
Horizontal & vertical female plug styles
Polarised mouldings
Moulded in green UL94-V0 flame retardant PA66
Professional rising clamp terminals
1.5mm2 (28-14AWG) solid & stranded cable
Captive screws
Guided pin alignment
UL & VDE approved
