SKF PCM 202210 E 20 mm Bore Plain Bearing, 22 mm OD, 48 kN
- RS 제품 번호:
- 233-0665
- 제조사 부품 번호:
- PCM 202210 E
- 제조업체:
- SKF
Subtotal (1 unit)*
₩3,139.60
재고있음
- 추가로 2026년 3월 02일 부터 46 개 단위 배송
- 추가로 2026년 3월 09일 부터 100 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩3,139.60 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 233-0665
- 제조사 부품 번호:
- PCM 202210 E
- 제조업체:
- SKF
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | SKF | |
| Product Type | Plain Bearing | |
| Bore Size | 20 mm | |
| Outside Diameter | 22 mm | |
| Static Load Rating | 48kN | |
| Dynamic Load Rating | 15.3kN | |
| Material | Polytetrafluoroethylene | |
| Width | 10 mm | |
| Standards/Approvals | No | |
| Series | PCM | |
| 모두 선택 | ||
|---|---|---|
브랜드 SKF | ||
Product Type Plain Bearing | ||
Bore Size 20 mm | ||
Outside Diameter 22 mm | ||
Static Load Rating 48kN | ||
Dynamic Load Rating 15.3kN | ||
Material Polytetrafluoroethylene | ||
Width 10 mm | ||
Standards/Approvals No | ||
Series PCM | ||
SKF Plain Bearing, PTFE Composite Body, 48kN Static Load Rating, 20mm Bore, 22mm OD - PCM 202210 E
Need a slim support element for your system's loads? Turn to this SKF plain bearing. It has a wall thickness of just 2mm, so takes up minimal space and calls for low clearance, but carries dynamic loads up to 15.3kN. This means it helps your equipment sail through intense handling tasks. Thanks to its PTFE running layer, the component works without friction to cut excessive wear to itself or the shaft out of the equation. Reliably good heat dissipation means your system runs cool.
Features & Benefits
• Durable sheet steel backing for effective impact resistance, so safe to use in demanding settings
• Tolerates sliding movement up to 2m/s, so keeps up with swivelling and stops misalignment damage
• Self-lubricating body removes the need for manual greasing
• Performs reliably in extreme temperatures from -200°C to +250°C
Applications
• Material handling
• Mining equipment
• Textile manufacturing
Can I use this product in a wet application?
Yes, the bearing's tin-plated backing shrugs off corrosion caused by moisture. This makes it a safe bet for applications that use a limited amount of water.
