Wieland 8375 Series PCB Terminal Block, 2-Contact, 7.5 mm Pitch, Through Hole, 2 Row
- RS 제품 번호:
- 181-3908
- 제조사 부품 번호:
- 25.700.0153.0
- 제조업체:
- Wieland
대량 구매 할인 기용 가능
View bulk pricing optionsSubtotal (1 pack of 10 units)*
₩27,680.00
재고있음
- 1,620 개 단위 배송 준비 완료
- 추가로 2026년 9월 03일 부터 1,200 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 | 한팩당* |
|---|---|---|
| 10 - 740 | ₩2,768.00 | ₩27,680.00 |
| 750 - 3990 | ₩2,658.00 | ₩26,580.00 |
| 4000 + | ₩2,546.00 | ₩25,460.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 181-3908
- 제조사 부품 번호:
- 25.700.0153.0
- 제조업체:
- Wieland
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Wieland | |
| Number of Contacts | 2 | |
| Product Type | PCB Terminal Block | |
| Pitch | 7.5mm | |
| Current | 30A | |
| Number of Rows | 2 | |
| Minimum Wire Size mm² | 0.14mm² | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 6mm² | |
| Minimum Wire Size AWG | 22AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | Straight | |
| Colour | Grey | |
| Voltage | 300V | |
| Length | 19.5mm | |
| Series | 8375 | |
| Width | 22mm | |
| Standards/Approvals | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 Wieland | ||
Number of Contacts 2 | ||
Product Type PCB Terminal Block | ||
Pitch 7.5mm | ||
Current 30A | ||
Number of Rows 2 | ||
Minimum Wire Size mm² 0.14mm² | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 6mm² | ||
Minimum Wire Size AWG 22AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation Straight | ||
Colour Grey | ||
Voltage 300V | ||
Length 19.5mm | ||
Series 8375 | ||
Width 22mm | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- DE
Modular PCB Screw Terminals
Modular PCB screw terminal system utilising rising clamp technology rated to 30A
Snap together terminals (in bags of 10) can be stacked together for a 7.5mm pitch, or with spacers for a 10mm pitch
Voltage Rating 7.5 pitch(500V), 10 pitch(690V)
Option marking tags, which clip onto the housing, provide terminal identification
Wire acceptance 4mm²
Rec. PCB hole dia. 1.3mm
Temperature Rating 115°C
