Phoenix Contact PCB Terminal Block, 4-Contact, 3.81 mm Pitch, Wave Soldering Mount, 1 Row
- RS 제품 번호:
- 566-095
- 제조사 부품 번호:
- 1724916
- 제조업체:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
₩346,176.00
현재 액세스할 수 없는 재고 정보 - 나중에 다시 확인해 주세요.
팩 | 한팩당 | 한팩당* |
|---|---|---|
| 1 + | ₩346,176.00 | ₩6,924.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 566-095
- 제조사 부품 번호:
- 1724916
- 제조업체:
- Phoenix Contact
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Phoenix Contact | |
| Number of Contacts | 4 | |
| Product Type | PCB Terminal Block | |
| Pitch | 3.81mm | |
| Current | 12A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.14mm² | |
| Mount Type | Wave Soldering Mount | |
| Maximum Wire Size mm² | 1mm² | |
| Minimum Wire Size AWG | 26AWG | |
| Maximum Wire Size AWG | 18AWG | |
| Orientation | 90° | |
| Colour | Green | |
| Wire Connection Method | Push-in | |
| Voltage | 160V | |
| Length | 12.7mm | |
| Width | 17.74mm | |
| Standards/Approvals | cULus Recognised Approval ID: E60425-19870330, CSA Approval ID: 13631 | |
| 모두 선택 | ||
|---|---|---|
브랜드 Phoenix Contact | ||
Number of Contacts 4 | ||
Product Type PCB Terminal Block | ||
Pitch 3.81mm | ||
Current 12A | ||
Number of Rows 1 | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.14mm² | ||
Mount Type Wave Soldering Mount | ||
Maximum Wire Size mm² 1mm² | ||
Minimum Wire Size AWG 26AWG | ||
Maximum Wire Size AWG 18AWG | ||
Orientation 90° | ||
Colour Green | ||
Wire Connection Method Push-in | ||
Voltage 160V | ||
Length 12.7mm | ||
Width 17.74mm | ||
Standards/Approvals cULus Recognised Approval ID: E60425-19870330, CSA Approval ID: 13631 | ||
- COO (Country of Origin):
- GR
The Phoenix Contact PCB terminal block provides a robust solution for electrical connectivity in compact spaces. Designed for efficiency, this terminal block integrates push-in spring connection technology, allowing for a straightforward and quick installation without the need for tools. Its green housing and linear pinning promote clear identification and easy integration into existing systems. With a nominal current rating of 12 A and a rated voltage of 160 V, it ensures reliable performance across a variety of applications.
Facilitates front mounted device integration through single direction connection
Two solder pins reduce mechanical strain, enhancing durability
Versatile design enables various position combinations for tailored solutions
Multi row arrangements possible, optimising space utilisation
