WAGO 2616 Series PCB Connector, 2-Contact, 10 mm Pitch, Through Hole, 1 Row
- RS 제품 번호:
- 224-842
- 제조사 부품 번호:
- 2616-1102/020-023
- 제조업체:
- WAGO
Subtotal (1 Box of 50 units)*
₩824,323.60
일시적 품절
- 2026년 4월 27일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩824,323.60 | ₩16,485.72 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 224-842
- 제조사 부품 번호:
- 2616-1102/020-023
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Number of Contacts | 2 | |
| Product Type | PCB Connector | |
| Pitch | 10mm | |
| Current | 76A | |
| Number of Rows | 1 | |
| Mount Type | Through Hole | |
| Minimum Wire Size mm² | 0.75mm² | |
| Housing Material | Polyamide 66 | |
| Maximum Wire Size mm² | 25mm² | |
| Minimum Wire Size AWG | 18 AWG | |
| Maximum Wire Size AWG | 4 AWG | |
| Orientation | 0° | |
| Colour | Green | |
| Wire Connection Method | Push-in | |
| Voltage | 1000 V | |
| Standards/Approvals | UL 1059, IEC/EN 60664-1, CSA | |
| Series | 2616 | |
| Width | 22.8 mm | |
| Depth | 32mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Number of Contacts 2 | ||
Product Type PCB Connector | ||
Pitch 10mm | ||
Current 76A | ||
Number of Rows 1 | ||
Mount Type Through Hole | ||
Minimum Wire Size mm² 0.75mm² | ||
Housing Material Polyamide 66 | ||
Maximum Wire Size mm² 25mm² | ||
Minimum Wire Size AWG 18 AWG | ||
Maximum Wire Size AWG 4 AWG | ||
Orientation 0° | ||
Colour Green | ||
Wire Connection Method Push-in | ||
Voltage 1000 V | ||
Standards/Approvals UL 1059, IEC/EN 60664-1, CSA | ||
Series 2616 | ||
Width 22.8 mm | ||
Depth 32mm | ||
- COO (Country of Origin):
- DE
The Wago PCB terminal block features innovative Push-in CAGE CLAMP technology, ensuring a highly efficient and tool-free operation for solid and fine-stranded conductors. Designed to accommodate up to 16 mm² wiring, this compact connector provides a robust solution for intricate circuit designs while maintaining an intuitive interface for easy user engagement.
Material is compliant with RoHS directives for environmental responsibility
Dimensions are optimised for compact PCB layouts without sacrificing functionality
Supports solid and fine stranded conductors for versatile connection options
High flammability rating enhances safety in electrical applications
