Molex 216700 Series Vertical Surface PCB Socket, 20-Contact, 2 Row, 0.35 mm Pitch Gold Plated Termination

RS 제품 번호:: 256-5268
제조사 부품 번호:: 216700-0209
제조업체:: Molex

Molex 216700 Series Vertical Surface PCB Socket, 20-Contact, 2 Row, 0.35 mm Pitch Gold Plated Termination

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

대량 구매 할인 기용 가능

Subtotal (1 tape of 50 units)*

₩13,009.60

재고있음

388 개 단위 배송 준비 완료

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

Tape(s)	Per Tape	한팩당*
1 - 1	₩13,009.60	₩259.44
2 - 4	₩12,614.80	₩251.92
5 - 9	₩12,238.80	₩244.40
10 +	₩11,862.80	₩236.88

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 256-5268
제조사 부품 번호:: 216700-0209
제조업체:: Molex

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Molex
	Number of Contacts	20
	Product Type	PCB Socket
	Number of Rows	2
	Sub Type	PCB Receptacle
	Pitch	0.35mm
	Current	5A
	Housing Material	Liquid Crystal Polymer
	Termination Type	Gold Plated Termination
	Mount Type	Surface
	Orientation	Vertical
	Connector System	Wire-to-Board
	Stacking Height	0.6mm
	Voltage	60 Vrms
	Series	216700
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	Contact Material	Copper Alloy
	Contact Plating	Gold
	Contact Gender	Male
	Standards/Approvals	EU RoHS, CHINA RoHS

	모두 선택
	브랜드 Molex
	Number of Contacts 20
	Product Type PCB Socket
	Number of Rows 2
	Sub Type PCB Receptacle
	Pitch 0.35mm
	Current 5A
	Housing Material Liquid Crystal Polymer
	Termination Type Gold Plated Termination
	Mount Type Surface
	Orientation Vertical
	Connector System Wire-to-Board
	Stacking Height 0.6mm
	Voltage 60 Vrms
	Series 216700
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	Contact Material Copper Alloy
	Contact Plating Gold
	Contact Gender Male
	Standards/Approvals EU RoHS, CHINA RoHS

COO (Country of Origin):: KR

The Molex connector is a SlimStack board-to-board receptacle, a ACB6+ series product. It has 0.35mm pitch, 0.60mm mated height, 1.90mm mated width and it is a 20 circuit receptacle. The metal used in the connector is copper alloy whereas the mating and termination part of the connector is gold plated. Operating temperature ranges between -40° to +85°C. Net weight of the receptacle is 10.512/mg. It is widely used in consumer, defence and medical devices.

Power nail structure enables power delivery up to 5.0A

Full armor design prevents damage during assembly

Wide alignment area provides easy mating

Maximum mating cycle durability is 30 cycles

Molex 216700 Series Vertical Surface PCB Socket, 20-Contact, 2 Row, 0.35 mm Pitch Gold Plated Termination
