WAGO 722 Series Straight PCB PCB Header, 3-Contact, 1 Row, 7.5 mm Pitch Solder

모든 PCB Sockets 열람하기

Subtotal (1 Box of 100 units)*

₩391,774.50

Add to Basket
수량 선택 또는 입력
일시적 품절
  • 2026년 7월 15일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es)
Per Box
한팩당*
1 +₩391,774.50₩3,917.55

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
224-318
제조사 부품 번호:
722-733
제조업체:
WAGO
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

WAGO

Number of Contacts

3

Product Type

PCB Header

Number of Rows

1

Sub Type

Header

Pitch

7.5mm

Current

12A

Housing Material

Polyamide 66

Termination Type

Solder

Mount Type

PCB

Orientation

Straight

Connector System

MCS

Voltage

50V

Series

722

Row Pitch

7.5mm

Minimum Operating Temperature

60°C

Maximum Operating Temperature

85°C

Contact Gender

Female

Contact Plating

Tin

Contact Material

Copper Alloy

Standards/Approvals

No

COO (Country of Origin):
DE
The Wago THT Female Header is designed to provide reliable board to board and board to wire connections with impeccable safety and performance. Boasting a robust 3 pole female header configuration with a 7.5 mm pin spacing, this model features a unique design that ensures 100% protection against mismating. Crafted with high grade materials, it guarantees durability and longevity under various environmental conditions.

Touch proof PCB outputs prevent accidental electric shock

Variable coding allows for flexible configurations according to user requirements

Anti rotation protection secures connection integrity in demanding environments

Designed to withstand a wide temperature range for diverse applications

Constructed with high quality polyamide insulation for exceptional durability
