WAGO 734 Series Straight PCB PCB Header, 5-Contact, 1 Row, 3.5 mm Pitch Solder
- RS 제품 번호:
- 222-857
- 제조사 부품 번호:
- 734-465
- 제조업체:
- WAGO
Subtotal (1 Box of 100 units)*
₩576,990.80
일시적 품절
- 2026년 4월 21일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩576,990.80 | ₩5,769.72 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 222-857
- 제조사 부품 번호:
- 734-465
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Product Type | PCB Header | |
| Number of Contacts | 5 | |
| Sub Type | Header | |
| Number of Rows | 1 | |
| Current | 10A | |
| Pitch | 3.5mm | |
| Termination Type | Solder | |
| Housing Material | Polyamide 66 | |
| Mount Type | PCB | |
| Orientation | Straight | |
| Connector System | MCS | |
| Voltage | 160 V | |
| Series | 734 | |
| Minimum Operating Temperature | 60°C | |
| Row Pitch | 3.5mm | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 100°C | |
| Contact Plating | Tin | |
| Contact Material | Copper Alloy | |
| Standards/Approvals | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Product Type PCB Header | ||
Number of Contacts 5 | ||
Sub Type Header | ||
Number of Rows 1 | ||
Current 10A | ||
Pitch 3.5mm | ||
Termination Type Solder | ||
Housing Material Polyamide 66 | ||
Mount Type PCB | ||
Orientation Straight | ||
Connector System MCS | ||
Voltage 160 V | ||
Series 734 | ||
Minimum Operating Temperature 60°C | ||
Row Pitch 3.5mm | ||
Contact Gender Female | ||
Maximum Operating Temperature 100°C | ||
Contact Plating Tin | ||
Contact Material Copper Alloy | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- DE
The Wago THT Female Header is an innovative solution tailored for seamless PCB integration, providing a reliable connection for board to board and board to wire applications. Designed with precision, it features a pin spacing of 3.5 mm, ensuring easy installation and effective space utilisation. Its light grey housing not only offers an aesthetically pleasing appearance but also ensures 100% protection against mismating, allowing for straightforward identification of inputs and outputs.
Anti rotation protection ensures stable connections
Touch proof outputs enhance user safety during operation
Designed for efficient board to board and board to wire connections
Constructed with high quality materials for durability
Compact design optimises space on the PCB
