Electromen - EM-241C DC MOTOR CONTROLLER, 24-48 V DC, 10 A

The EM-241C-48V is a full bridge brushed DC-motor starter.

It is designed to work in a wide range of applications and offers a host of adjustments to optimise control for each application.

The drive has adjustable acceleration and deceleration ramps to produce smooth starts and stops,adjustable current limit protects motor against overcurrent and can also be used to provide an end-stop on current trip.

The device has also two settable speeds, a useful feature for positioning applications.

Control inputs are present for basic forward, backward and stop commands, as well as limit switch inputs to define end stops

This device has also two settable speeds, this can be activated by dedicated input. The same input can be used for analogue speed control signal 0-5V

Fault output can indicate current trip, over-current or zero-current conditions. It can also be pulled down to ground to disable the drive, if required

C-version includes wo new parameter: freewheel options for release the rotor of motor, selectable pwm frequency (16kHz pwm being inaudible though current handling capacity is reduced)

There are two selectable control modes, in continuous mode the motor runs as long as the control is active, in impulse mode it will operate from a momentary command

Special settings are also available for start-up kick and auto reverse

For parameters setting there are 3 options: EM-236 interface unit, EM-268 with Menthol-Lite PC-program and EM-326 with Menthol-App application for smartphone.

Features and Benefits

24-48Vdc, 7-10A continuous, 20-25A peak

Speed, direction, current limiting, soft start/stop and auto-reverse control

Limit switch inputs for end of travel

Compact and DIN rail mountable;Compact with high current output

Current limit

Zero current limit

Overvoltage brake

Speed setting

Flexible control inputs

Impulse / continuous mode

DIN rail mountable

Digital parameter - C-version replaces A and B versions

C-firmware can be loaded B ver. card

C.version available with Molex connector

Current limit setting input ( new )

Freewheel options ( new )

* Continuous current output when ambient temp is <50°C

12-24Vdc version drive =

15A at 100% speed / 10A at 5-99% speed pwm=2kHz

10A at 100% speed / 5A at 5-99% speed pwm=16kHz

Peak ( 5s.) 30A at 2khz pwm and 25A at 16kHz pwm

Small size

High current output

Current limit

Zero current limit

Overvoltage brake

Speed setting

Flexible control inputs

Impulse / continuous mode

Rail base mountable

Digital parameter setting

48V version of EM-241C

Current limit setting input ( new )

Freewheel options ( new )

2 or 16kHz PWM freq. ( new )

Prog ver C-v1.5

Eight input logic option

Overvoltage range increased

Analog speed input range set

모두 선택	제품 정보	값
	브랜드	Electromen OY
	Product Type	DC Motor Controller
	Control Function	PWM
	Output Voltage	48 V, 24 V
	Supply Voltage	20/60 V dc
	Current Rating	10 A
	Overall Length	42mm
	Overall Width	72mm
	Overall Depth	25 mm
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	60°C
	Standards/Approvals	EN - 55022B

	모두 선택
	브랜드 Electromen OY
	Product Type DC Motor Controller
	Control Function PWM
	Output Voltage 48 V, 24 V
	Supply Voltage 20/60 V dc
	Current Rating 10 A
	Overall Length 42mm
	Overall Width 72mm
	Overall Depth 25 mm
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 60°C
	Standards/Approvals EN - 55022B

Electromen OY DC Motor Controller, 20/60 V dc, 10 A, PWM Function
