Omron E6F-A Series Absolute Absolute Encoder 12V dc, 360 ppr ppr, NPN Open Collector Signal, Solid Type, 10 mm Shaft
- RS 제품 번호:
- 822-6392
- 제조사 부품 번호:
- E6F-AB3C-C 360 5M
- 제조업체:
- Omron
Subtotal (1 unit)*
₩2,251,060.00
재고있음
- 2 개 단위 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩2,251,060.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 822-6392
- 제조사 부품 번호:
- E6F-AB3C-C 360 5M
- 제조업체:
- Omron
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Omron | |
| Encoder Technology | Absolute | |
| Product Type | Absolute Encoder | |
| Series | E6F-A | |
| Pulses Per Revolution | 360ppr | |
| Maximum Revolutions | 5000rpm | |
| Output Signal Type | NPN Open Collector | |
| Shaft Type | Solid | |
| Shaft Diameter | 10mm | |
| Interface Type | BCD | |
| IP Rating | IP65 | |
| Terminal Type | Cable | |
| Maximum Supply Voltage | 12V dc | |
| Minimum Operating Temperature | -10°C | |
| Overall Depth | 60mm | |
| Overall Height | 85mm | |
| Standards/Approvals | IEC | |
| Overall Width | 60mm | |
| Maximum Operating Temperature | 70°C | |
| Mount Type | Chassis | |
| Switching Frequency | 10kHz | |
| 모두 선택 | ||
|---|---|---|
브랜드 Omron | ||
Encoder Technology Absolute | ||
Product Type Absolute Encoder | ||
Series E6F-A | ||
Pulses Per Revolution 360ppr | ||
Maximum Revolutions 5000rpm | ||
Output Signal Type NPN Open Collector | ||
Shaft Type Solid | ||
Shaft Diameter 10mm | ||
Interface Type BCD | ||
IP Rating IP65 | ||
Terminal Type Cable | ||
Maximum Supply Voltage 12V dc | ||
Minimum Operating Temperature -10°C | ||
Overall Depth 60mm | ||
Overall Height 85mm | ||
Standards/Approvals IEC | ||
Overall Width 60mm | ||
Maximum Operating Temperature 70°C | ||
Mount Type Chassis | ||
Switching Frequency 10kHz | ||
General Purpose Incremental Encoders
Incremental Encoders output a pulse string according to the rotational displacement of an axis. The number of rotations can be detected by counting the number of pulses. Improved reliability with reverse connection and load shortcircuit
protection..
Moment of inertia: 1x10−6 kg·m2 max.; 3 x 10−7 kg·m2 max. at 600 P/R max
External diameter E6A2: 25 mm
External diameter E6B2: 40 mm
External diameter E6C2: 50 mm
External diameter E6C3: 50 mm
External diameter E6FA: 60 mm
Omron Incremental Rotary Encoders
