Silicon Labs, 32bit ARM Cortex M0+, EFM32ZG Microcontroller, 24MHz, 32 kB Flash, 32-Pin QFN
- RS 제품 번호:
- 196-3330
- 제조사 부품 번호:
- EFM32ZG210F32-B-QFN32
- 제조업체:
- Silicon Labs
대량 구매 할인 기용 가능
Subtotal (1 pack of 5 units)**
₩22,090.00
2970 재고있음 5-9영업일내 홍콩 발송*
* 배송 날짜는 선택한 수량과 배송 주소에 따라 달라질 수 있습니다.
재고 확인하기
수량 | 한팩당 | 한팩당** |
|---|---|---|
| 5 - 120 | ₩4,418.00 | ₩22,090.00 |
| 125 - 240 | ₩4,320.24 | ₩21,601.20 |
| 245 + | ₩4,226.24 | ₩21,131.20 |
** 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 196-3330
- 제조사 부품 번호:
- EFM32ZG210F32-B-QFN32
- 제조업체:
- Silicon Labs
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Silicon Labs | |
| Family Name | EFM32ZG | |
| Package Type | QFN | |
| Mounting Type | Surface Mount | |
| Pin Count | 32 | |
| Device Core | ARM Cortex M0+ | |
| Data Bus Width | 32bit | |
| Program Memory Size | 32 kB | |
| Maximum Frequency | 24MHz | |
| RAM Size | 4 kB | |
| Number of PWM Units | 1 x 16 bit | |
| Number of SPI Channels | 1 | |
| Number of UART Channels | 2 | |
| Number of USART Channels | 1 | |
| Typical Operating Supply Voltage | 1.9 → 3.8 V | |
| Number of I2C Channels | 1 | |
| ADCs | 4 x 12 bit | |
| Height | 0.85mm | |
| Width | 6mm | |
| Instruction Set Architecture | RISC | |
| Dimensions | 6 x 6 x 0.85mm | |
| Length | 6mm | |
| Minimum Operating Temperature | -40 °C | |
| Number of ADC Units | 1 | |
| Program Memory Type | Flash | |
| Maximum Operating Temperature | +85 °C | |
| Pulse Width Modulation | 1 (3 x 16 bit) | |
모두 선택 | ||
|---|---|---|
브랜드 Silicon Labs | ||
Family Name EFM32ZG | ||
Package Type QFN | ||
Mounting Type Surface Mount | ||
Pin Count 32 | ||
Device Core ARM Cortex M0+ | ||
Data Bus Width 32bit | ||
Program Memory Size 32 kB | ||
Maximum Frequency 24MHz | ||
RAM Size 4 kB | ||
Number of PWM Units 1 x 16 bit | ||
Number of SPI Channels 1 | ||
Number of UART Channels 2 | ||
Number of USART Channels 1 | ||
Typical Operating Supply Voltage 1.9 → 3.8 V | ||
Number of I2C Channels 1 | ||
ADCs 4 x 12 bit | ||
Height 0.85mm | ||
Width 6mm | ||
Instruction Set Architecture RISC | ||
Dimensions 6 x 6 x 0.85mm | ||
Length 6mm | ||
Minimum Operating Temperature -40 °C | ||
Number of ADC Units 1 | ||
Program Memory Type Flash | ||
Maximum Operating Temperature +85 °C | ||
Pulse Width Modulation 1 (3 x 16 bit) | ||
