Digitron Differential Digital Pressure Meter With 2 Pressure Port/s, Max Pressure Measurement 130 mbar
- RS 재고 번호:
- 437-9120
- 제조 부품 번호:
- PM-20
- 제조업체:
- Digitron
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
Subtotal (1 unit)*
₩509,480.00
현재 액세스할 수 없는 재고 정보
단위당 | 한팩당 |
|---|---|
| 1 + | ₩509,480.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 재고 번호:
- 437-9120
- 제조 부품 번호:
- PM-20
- 제조업체:
- Digitron
사양
기술적 참조
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Digitron | |
| Accuracy | ±0.2 % | |
| Product Type | Digital Pressure Meter | |
| Number of Pressure Ports | 2 | |
| Maximum Pressure Measurement | 130mbar | |
| Minimum Pressure Measurement | 0bar | |
| Pressure Port Type | Differential | |
| IP Rating | IP67 | |
| Minimum Operating Temperature | -10°C | |
| Battery Type | AA | |
| Battery Life | 200h | |
| Maximum Operating Temperature | 50°C | |
| Display Type | LCD | |
| Length | 155mm | |
| Height | 40mm | |
| Width | 67 mm | |
| Standards/Approvals | No | |
| Weight | 180g | |
| Hazardous Area Certification | No | |
| Calibrated | RSCAL | |
| 모두 선택 | ||
|---|---|---|
브랜드 Digitron | ||
Accuracy ±0.2 % | ||
Product Type Digital Pressure Meter | ||
Number of Pressure Ports 2 | ||
Maximum Pressure Measurement 130mbar | ||
Minimum Pressure Measurement 0bar | ||
Pressure Port Type Differential | ||
IP Rating IP67 | ||
Minimum Operating Temperature -10°C | ||
Battery Type AA | ||
Battery Life 200h | ||
Maximum Operating Temperature 50°C | ||
Display Type LCD | ||
Length 155mm | ||
Height 40mm | ||
Width 67 mm | ||
Standards/Approvals No | ||
Weight 180g | ||
Hazardous Area Certification No | ||
Calibrated RSCAL | ||
해당 안됨
PM-20 and PM-80 0-130mbar
The PM Series is a suitable replacement for the conventional U-Tube, having a fast response coupled with high accuracy and at a low cost. The PM-80 instrument has the advantages of user selectable measurement units and smoothing function ensuring the range continues to meet the performance and cost demands of today's HVAC professional.
Differential input – 8mm tube connectors
Water resistant (IP67 rated)
Rugged case with protective rubber boot
Magnetic attachment or tilt stand
Push button “Zero” and “Hold” features
Backlit digital display
Auto power off after 12 minutes
0-130 mbar measurement
0.01 resolution up to 19.99 mbar, then auto switches to 0.1 resolution
Measurement unit options (selectable on PM-80)
Smoothing function (available on PM-80)
