Ewellix Makers in Motion Linear Guide Carriage LLTHC 20 LA T0 P5 LLTHC 20 LA T0 P5 Series, 24.4 kN Dynamic Load
- RS 제품 번호:
- 184-9738
- 제조사 부품 번호:
- LLTHC 20 LA T0 P5
- 제조업체:
- Ewellix Makers in Motion
대량 구매 할인 기용 가능
Subtotal (1 unit)*
₩299,893.84
일시적 품절
- 2026년 3월 23일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 - 4 | ₩299,893.84 |
| 5 + | ₩287,908.84 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 184-9738
- 제조사 부품 번호:
- LLTHC 20 LA T0 P5
- 제조업체:
- Ewellix Makers in Motion
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Ewellix Makers in Motion | |
| Product Type | Linear Guide Carriage | |
| Series | LLTHC 20 LA T0 P5 | |
| Carriage Length | 89.5mm | |
| Carriage Width | 63mm | |
| Dynamic Load Rating | 24.4kN | |
| Static Load Rating | 44.6kN | |
| Acceptable Rail Width | 20mm | |
| Standards/Approvals | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 Ewellix Makers in Motion | ||
Product Type Linear Guide Carriage | ||
Series LLTHC 20 LA T0 P5 | ||
Carriage Length 89.5mm | ||
Carriage Width 63mm | ||
Dynamic Load Rating 24.4kN | ||
Static Load Rating 44.6kN | ||
Acceptable Rail Width 20mm | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- TW
Side and inner seals integrated in carriage by standard
Equal load carrying capacity with top rigidity
Rails with dual reference sides
Low roughness on the rail surface
High performance in relation to required space
Low friction and wear with smooth running on high quality surfaces
Easy installation and adjustment with low maintenance
Long, flanged carriage with standard height is available from size 20 to 45. Equipped with 4 larger threads for mounting from top and bottom side. The extended length provides increased load rating and rigidity.
