Lumileds 3.5 V Green LED Surface Mount Surface LUXEON CZ

RS 제품 번호:: 173-6496
제조사 부품 번호:: L1CU-GRN1000000000
제조업체:: Lumileds

Lumileds 3.5 V Green LED Surface Mount Surface LUXEON CZ

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

대량 구매 할인 기용 가능

Subtotal (1 reel of 1000 units)*

₩1,703,280.00

마지막 RS 재고

최종적인 1,000 개 unit(s)이 배송 준비 됨

수량	한팩당	릴당*
1000 - 1000	₩1,703.28	₩1,703,844.00
2000 - 3000	₩1,669.44	₩1,669,816.00
4000 +	₩1,635.60	₩1,636,352.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 173-6496
제조사 부품 번호:: L1CU-GRN1000000000
제조업체:: Lumileds

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Lumileds
	Product Type	LED
	LED Colour	Green
	Package Type	Surface Mount
	Maximum Forward Current	350mA
	Mount Type	Surface
	Packaging	Tape & Reel
	Forward Voltage	3.5V
	Number of Pins	2
	Viewing Angle	120 °
	Lens Dimensions	2 x 2 mm
	LED Luminous Flux	99 lm
	Lens Shape	Square
	Dominant Wavelength	540 nm
	Standards/Approvals	RoHS
	Lens Finish	Clear
	Series	LUXEON CZ
	Lens Colour	Green
	Automotive Standard	No

	모두 선택
	브랜드 Lumileds
	Product Type LED
	LED Colour Green
	Package Type Surface Mount
	Maximum Forward Current 350mA
	Mount Type Surface
	Packaging Tape & Reel
	Forward Voltage 3.5V
	Number of Pins 2
	Viewing Angle 120 °
	Lens Dimensions 2 x 2 mm
	LED Luminous Flux 99 lm
	Lens Shape Square
	Dominant Wavelength 540 nm
	Standards/Approvals RoHS
	Lens Finish Clear
	Series LUXEON CZ
	Lens Colour Green
	Automotive Standard No

Datasheet

COO (Country of Origin):: MY

LUXEON CZ Color Line is an optically advanced portfolio of Color and White LEDs. Designed to maximize punch, the LUXEON CZ Color Line is the optimal LED solution for architecture, entertainment and emergency vehicle lighting applications.

Small and symmetrical 2x2mm² package

Industry leading Hot/Cold Factors and the lowest thermal resistance

Maximized punch (cd/lm)

Architectural & Entertainment

Lamps

Color Tunable

Specialty Lighting

Emergency Vehicle
