MEAN WELL LED Driver, 36 V Output, 18 W Output, 0.5 A

RS 제품 번호:: 660-0243
Distrelec 제품 번호:: 169-97-788
제조사 부품 번호:: LPH-18-36
제조업체:: MEAN WELL

MEAN WELL LED Driver, 36 V Output, 18 W Output, 0.5 A

대량 구매 할인 기용 가능

Subtotal (1 unit)*

₩11,148.40

일시적 품절

2026년 3월 10일 부터 56 개 단위 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 - 4	₩11,148.40
5 - 9	₩10,922.80
10 - 24	₩10,603.20
25 - 49	₩10,490.40
50 +	₩10,283.60

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 660-0243
Distrelec 제품 번호:: 169-97-788
제조사 부품 번호:: LPH-18-36
제조업체:: MEAN WELL

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	MEAN WELL
	Output Voltage	36 V
	Product Type	LED Driver
	Maximum Output Power	18W
	Input Voltage	180 → 264 V ac, 254 → 370 V dc
	Mount Type	Panel
	Sub Type	LED Driver
	Terminal Type	Wire
	Input Voltage Type	AC/DC
	IP Rating	IP67
	Driver Current	0.5 A
	Operating Modes	Constant Voltage
	Number of Outputs	1
	Standards/Approvals	UL, EN, CSA, CE
	Series	LPH-18
	Configuration	Enclosed
	Primary Type	AC-DC
	Power Dissipation	18W

	모두 선택
	브랜드 MEAN WELL
	Output Voltage 36 V
	Product Type LED Driver
	Maximum Output Power 18W
	Input Voltage 180 → 264 V ac, 254 → 370 V dc
	Mount Type Panel
	Sub Type LED Driver
	Terminal Type Wire
	Input Voltage Type AC/DC
	IP Rating IP67
	Driver Current 0.5 A
	Operating Modes Constant Voltage
	Number of Outputs 1
	Standards/Approvals UL, EN, CSA, CE
	Series LPH-18
	Configuration Enclosed
	Primary Type AC-DC
	Power Dissipation 18W

COO (Country of Origin):: TW

RS - 18W Waterproof (IP67) SMPSU

External switch mode encapsulated IP67 rated power supplies

High efficiency, long life and high reliability

Designed for indoor or outdoor installations

Suitable for LED lighting and moving sign applications

100% full load burn-in test

Fully regulated output

Short circuit, over-load, over-voltage, over-temperature protection

300mm un-terminated, 2-core 18AWG input lead

300mm un-terminated, 2-core 18AWG output lead

UL1310 Class 2 power unit, pass LPS

EMC compliance to EN 55022 Class B

Harmonic current compliance to EN 61000-3-2,-3

Note

For Industrial Use Only, not in scope of Regulation (EC) No 125/2009.

Power derates above 50°C.
MTBF to MIL-HDBK-217F.

Standards

TUV EN 60950-1, EN 61347-2-13, UL 1310 Class 2, CAN/CSA C22.2 No. 223-M91

MEAN WELL LED Driver, 36 V Output, 18 W Output, 0.5 A

RS - 18W Waterproof (IP67) SMPSU

Note

Standards
