MEAN WELL LED Driver, 12 V Output, 40 W Output, 3.33 A 3 in 1 Dimming
- RS 제품 번호:
- 424-927
- Distrelec 제품 번호:
- 301-34-819
- 제조사 부품 번호:
- HLG-40H-12
- 제조업체:
- MEAN WELL
Subtotal (1 unit)*
₩57,697.20
일시적 품절
- 2026년 3월 09일 부터 2 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩57,697.20 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 424-927
- Distrelec 제품 번호:
- 301-34-819
- 제조사 부품 번호:
- HLG-40H-12
- 제조업체:
- MEAN WELL
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | MEAN WELL | |
| Product Type | LED Driver | |
| Output Voltage | 12 V | |
| Maximum Output Power | 40W | |
| Input Voltage | 127/431 V dc | |
| Mount Type | Screw | |
| Sub Type | LED Driver | |
| Dimming Operation | 3 in 1 Dimming | |
| Input Voltage Type | DC | |
| IP Rating | IP65, IP67 | |
| Operating Modes | Constant Current/Constant Voltage | |
| LED Voltage | 7.2/12 V | |
| Driver Current | 3.33 A | |
| Number of Outputs | 1 | |
| Series | HLG | |
| Standards/Approvals | J61347-1, design refer to BS EN/EN60335-1(by request), GB19510.14, UL8750(type”HL”), KC61347-2-13(except for AB-type), CSA C22.2 No. 250.0-08, EAC TP TC 004, KC61347-1, BS EN/ES/NZS 61347-2-13 independent, IP65 or IP67 Approved, BS EN/ES/NZS 61347-1, J61347-2-13 (except for B,AB and D-type), GB19510.1 | |
| Power Dissipation | 0.5W | |
| 모두 선택 | ||
|---|---|---|
브랜드 MEAN WELL | ||
Product Type LED Driver | ||
Output Voltage 12 V | ||
Maximum Output Power 40W | ||
Input Voltage 127/431 V dc | ||
Mount Type Screw | ||
Sub Type LED Driver | ||
Dimming Operation 3 in 1 Dimming | ||
Input Voltage Type DC | ||
IP Rating IP65, IP67 | ||
Operating Modes Constant Current/Constant Voltage | ||
LED Voltage 7.2/12 V | ||
Driver Current 3.33 A | ||
Number of Outputs 1 | ||
Series HLG | ||
Standards/Approvals J61347-1, design refer to BS EN/EN60335-1(by request), GB19510.14, UL8750(type”HL”), KC61347-2-13(except for AB-type), CSA C22.2 No. 250.0-08, EAC TP TC 004, KC61347-1, BS EN/ES/NZS 61347-2-13 independent, IP65 or IP67 Approved, BS EN/ES/NZS 61347-1, J61347-2-13 (except for B,AB and D-type), GB19510.1 | ||
Power Dissipation 0.5W | ||
제외
- COO (Country of Origin):
- CN
The MEANWELL AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC and Output 12Vdc at 3.33A and IP67 and Cable output.
Warranty pack 84 Months Bring-In
RoHS Compliant
Packing quantity 20
