제조사부품번호

MEAN WELL, 24 V Output, 100 W Output 10V PWM Signal or Resistance, 0 to 10 V dc

RS 제품 번호:: 106-566
Distrelec 제품 번호:: 301-34-547
제조사 부품 번호:: ELG-100-24A-3Y
제조업체:: MEAN WELL

MEAN WELL, 24 V Output, 100 W Output 10V PWM Signal or Resistance, 0 to 10 V dc

Subtotal (1 unit)*

₩64,484.00

일시적 품절

2026년 7월 09일 부터 배송

더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.

수량	한팩당
1 +	₩64,484.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:: 106-566
Distrelec 제품 번호:: 301-34-547
제조사 부품 번호:: ELG-100-24A-3Y
제조업체:: MEAN WELL

참조 문서

제정법과 컴플라이언스

제품 세부 사항

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	MEAN WELL
	Product Type	LED Driver
	Output Voltage	24 V
	Maximum Output Power	100W
	Input Voltage	24 V
	Dimming Operation	10V PWM Signal or Resistance, 0 to 10 V dc
	Input Voltage Type	AC/DC
	IP Rating	IP67, IP65
	Series	ELG-100
	Standards/Approvals	UL8750(typeHL), KN61547, KC KN15, IS 15885(Part 2/Sec13), IEC/BS EN/ES/NZS 61347-2-13, IEC/BS EN/ES/NZS 61347-1, GB17743, GB17625.1 EAC TP TC 020, EAC TP TC 020, EAC TP TC 004, CSA C22.2 No. 250.13-12, BS EN/EN62384, BS EN/EN61547, BS EN/EN61000-4-2, BS EN/EN61000-3-3, BS EN/EN61000-3-2 Class C (load60%), BS EN/EN55015

	모두 선택
	브랜드 MEAN WELL
	Product Type LED Driver
	Output Voltage 24 V
	Maximum Output Power 100W
	Input Voltage 24 V
	Dimming Operation 10V PWM Signal or Resistance, 0 to 10 V dc
	Input Voltage Type AC/DC
	IP Rating IP67, IP65
	Series ELG-100
	Standards/Approvals UL8750(typeHL), KN61547, KC KN15, IS 15885(Part 2/Sec13), IEC/BS EN/ES/NZS 61347-2-13, IEC/BS EN/ES/NZS 61347-1, GB17743, GB17625.1 EAC TP TC 020, EAC TP TC 020, EAC TP TC 004, CSA C22.2 No. 250.13-12, BS EN/EN62384, BS EN/EN61547, BS EN/EN61000-4-2, BS EN/EN61000-3-3, BS EN/EN61000-3-2 Class C (load60%), BS EN/EN55015

Datasheet - ELG-100-24A-3Y

COO (Country of Origin):: CN

The MEANWELL versatile AC-DC single output LED driver with mix mode (CV+CC) and PFC. It offers an output of 24VDC at 4A, with the ability to adjust CC using a potentiometer. With an IP65 rating and metal housing, it ensures durability and reliability for various applications.

AC-DC Single output LED Driver with Mix Mode (CV+CC) and PFC

Output of 24VDC at 4A with adjustable CC

Suitable for a wide input voltage range of 100-305V

IP65 rating for enhanced protection

Metal housing for durability and longevity

Ideal for LED lighting and display power supply applications

MEAN WELL, 24 V Output, 100 W Output 10V PWM Signal or Resistance, 0 to 10 V dc
