RS PRO Hall Effect Sensor Flange, NPN Output, Rectangular Body, 40 V dc 24V dc
- RS 제품 번호:
- 289-2085
- 제조업체:
- RS PRO
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
Subtotal (1 unit)*
₩13,888.00
마지막 RS 재고
- 최종적인 299 개 unit(s)이 배송 준비 됨
수량 | 한팩당 |
|---|---|
| 1 + | ₩13,888.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 289-2085
- 제조업체:
- RS PRO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | RS PRO | |
| Product Type | Hall Effect Sensor | |
| Output Type | NPN | |
| Body Style | Rectangular | |
| Terminal Type | 3-Wire | |
| Mount Type | Flange | |
| Maximum DC Voltage | 40V dc | |
| Maximum Supply Voltage | 24V dc | |
| Minimum Operating Temperature | -20°C | |
| Length | 23mm | |
| Standards/Approvals | RoHS, REACH | |
| Width | 13.9mm | |
| Depth | 5.9mm | |
| Maximum Operating Temperature | 85°C | |
| IP Rating | IP67 | |
| Housing Material | ABS | |
| 모두 선택 | ||
|---|---|---|
브랜드 RS PRO | ||
Product Type Hall Effect Sensor | ||
Output Type NPN | ||
Body Style Rectangular | ||
Terminal Type 3-Wire | ||
Mount Type Flange | ||
Maximum DC Voltage 40V dc | ||
Maximum Supply Voltage 24V dc | ||
Minimum Operating Temperature -20°C | ||
Length 23mm | ||
Standards/Approvals RoHS, REACH | ||
Width 13.9mm | ||
Depth 5.9mm | ||
Maximum Operating Temperature 85°C | ||
IP Rating IP67 | ||
Housing Material ABS | ||
- COO (Country of Origin):
- CN
RS PRO 24V Unipolar Flat Packed Hall Effect Sensor
A reliable and accurate 24V hall effect position sensor with a Unipolar design. The Unipolar flat packed hall effect sensor is ideal for a wide range of non-contact operations including position control, speed measurement, level sensing and flow detection applications.
The hardwearing and durable hall sensor is encapsulated within a flat packed ABS body protected to IP67 with excellent strength and corrosion resistance highly suited for use in the automotive industry.
An easy to mount threaded design connected with 3 (red, white, black) AWG 24 wires rated to UL 1007/1569 suited for internal wiring applications.
Features and Benefits
Unipolar operation
3 wire termination
Flat Packed design
23 x 13.9 x 5.9mm
Applications
No contact sensing;Position control;Speed measurement (RPM);Level sensing;Flow detection
For a suitable sensing magent please see RS PRO 277-3631
