SMC PFMB720 Series Flow Sensor Flow Sensor for Air, 2L/min Min, 200 L/min Max Calibrated
- RS 제품 번호:
- 402-805
- 제조사 부품 번호:
- PFMB7202-F06-B
- 제조업체:
- SMC
Subtotal (1 unit)*
₩605,435.20
재고있음
- 1 개 단위 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩605,435.20 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 402-805
- 제조사 부품 번호:
- PFMB7202-F06-B
- 제조업체:
- SMC
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | SMC | |
| Product Type | Flow Sensor | |
| Media Monitored | Air | |
| Device Type | Flow Sensor | |
| Minimum Flow Rate | 2L/min | |
| Housing Material | Germanium Tetrafluoride, FKM, Hydrogenated Nitrile Butadiene Rubber, PPS, ADC, 304 Stainless Steel, Silicon, Gold, PBT, Brass Nickel Plated | |
| Maximum Flow Rate | 200L/min | |
| Connection Type | NPT 1/4, RC 1/4, NPT 1/2, Plug Connection, G 1/4, RC 3/4, G 3/4, RC 1/2, NPT 3/4, G 1/2 | |
| Maximum Pressure | 1.2MPa | |
| IsCalibrated | Yes | |
| Maximum Supply Voltage | 24V dc | |
| IP Rating | IP40 | |
| Minimum Media Temperature | 0°C | |
| Minimum Operating Temperature | 0°C | |
| Maximum Media Temperature | 50°C | |
| Maximum Operating Temperature | 50°C | |
| Series | PFMB720 | |
| Standards/Approvals | RoHS, CE, UL (CSA) | |
| Current Rating | 80 mA | |
| 모두 선택 | ||
|---|---|---|
브랜드 SMC | ||
Product Type Flow Sensor | ||
Media Monitored Air | ||
Device Type Flow Sensor | ||
Minimum Flow Rate 2L/min | ||
Housing Material Germanium Tetrafluoride, FKM, Hydrogenated Nitrile Butadiene Rubber, PPS, ADC, 304 Stainless Steel, Silicon, Gold, PBT, Brass Nickel Plated | ||
Maximum Flow Rate 200L/min | ||
Connection Type NPT 1/4, RC 1/4, NPT 1/2, Plug Connection, G 1/4, RC 3/4, G 3/4, RC 1/2, NPT 3/4, G 1/2 | ||
Maximum Pressure 1.2MPa | ||
IsCalibrated Yes | ||
Maximum Supply Voltage 24V dc | ||
IP Rating IP40 | ||
Minimum Media Temperature 0°C | ||
Minimum Operating Temperature 0°C | ||
Maximum Media Temperature 50°C | ||
Maximum Operating Temperature 50°C | ||
Series PFMB720 | ||
Standards/Approvals RoHS, CE, UL (CSA) | ||
Current Rating 80 mA | ||
- COO (Country of Origin):
- JP
The SMC State-of-the-art digital flow switch designed for precise flow measurement and control in various industrial applications. This device facilitates enhanced energy efficiency by enabling accurate flow monitoring across a wide range of fluids including air and nitrogen. Engineered for reliability, it features a robust design that withstands demanding environments, ensuring consistent performance. With integrated flow adjustment capabilities and straightforward installation, this flow switch reduces setup complexity and optimises space requirements.
Mounting variations enable flexible installation options
External input functionality allows for remote control capabilities
Designed to minimise moisture contact, preserving sensor accuracy
Built-in security features protect against unintended adjustments
