SMC PFMB7102 Series, DIN Rail Flow Controller, 1000L/min, PNP Open Collector Output 12V

모든 Flow Controllers 열람하기

Subtotal (1 unit)*

₩636,500.00

Add to Basket
수량 선택 또는 입력
재고있음
  • 4 개 단위 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량
한팩당
1 +₩636,500.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
235-3375
Distrelec 제품 번호:
110-73-989
제조사 부품 번호:
PFMB7102-F04-E
제조업체:
SMC
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

SMC

Product Type

Flow Controller

Maximum Flow Rate

1000L/min

Control Output

PNP Open Collector

Mount Type

DIN Rail

Display Screen

LCD

Minimum Operating Temperature

0°C

Maximum Supply Voltage

12V

Maximum Operating Temperature

+50°C

Hazardous Area Certification

No

Standards/Approvals

CE

Series

PFMB7102

Current Rating

80mA

COO (Country of Origin):
JP

SMC PFMB7102 Series Flow Controller, 1000L/min Maximum Flow Rate, 12V Maximum Supply Voltage - PFMB7102-F04-E


This flow controller monitors and regulates fluid flow in industrial control systems, providing Visual feedback via an integrated LCD for real-time readout and operational adjustments within controlled environments. It is designed for mounting on a DIN rail and operates within standard ambient thermal limits for general industrial use.

Features and Benefits:


• Supports maximum flow up to 1000 L/min for high-throughput processes
• Operates from a maximum 12 V supply for low-voltage systems
• Draws 80 mA current minimising power consumption on instrumentation loops
• PNP open-collector control output for simple sourcing signal integration
• Rated for ambient use between 0°C and +50°C for controlled plant areas
• CE approved confirming conformity with applicable EU directives

Applications


• Suitable for process skids in non-hazardous areas
• Ideal for integration into panel-mounted fluid monitoring systems
• Used with PLCs requiring PNP sourcing signals for control logic
• Can be used for flow verification in maintenance routines
• Suitable for systems needing DIN rail-mounted instrumentation

What type of output signal does it provide for control systems?


It offers a PNP open-collector output compatible with sourcing input modules and relays.

How is the unit intended to be installed in a control cabinet?


The device is designed for DIN rail mounting to fit standard industrial enclosures.

What display capability is available for operators?


An integrated LCD provides immediate Visual feedback of the measured flow value.

What are the acceptable ambient temperature limits for operation?


The unit functions within an operating range from 0°C to +50°C.

Is this suitable for classified hazardous-area installations?


It is not certified for hazardous areas and is intended for non-hazardous environments.
