Schneider Electric PanelSeT Series Fibreglass Double Reinforced Polyester 2-Door Floor Standing Enclosure, Transparent
- RS 제품 번호:
- 438-772
- 제조사 부품 번호:
- NSYPLA7124TG
- 제조업체:
- Schneider Electric
Subtotal (1 unit)*
₩5,659,848.00
제조사가 재고 비축중
- 2026년 11월 17일 부터 배송 준비 완료
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩5,659,848.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 438-772
- 제조사 부품 번호:
- NSYPLA7124TG
- 제조업체:
- Schneider Electric
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Schneider Electric | |
| Number of Doors | 2 | |
| Product Type | Floor Standing Enclosure | |
| IP Rating | IP65 | |
| Construction | Sealed Top and Bottom Part Assembled with Side Parts | |
| Series | PanelSeT | |
| Door Type | Transparent | |
| Body Material | Fibreglass Double Reinforced Polyester | |
| Colour | Grey | |
| External Width | 1.25m | |
| External Depth | 420mm | |
| External Height | 750mm | |
| NEMA Rating | NEMA 1, NEMA 2, NEMA 13, NEMA 12 | |
| Colour RAL | RAL 7035 | |
| Standards/Approvals | UL 508 A, IEC 62208, UL/cUL, DNV Marine Veritas | |
| IK Rating | IK08 | |
| 모두 선택 | ||
|---|---|---|
브랜드 Schneider Electric | ||
Number of Doors 2 | ||
Product Type Floor Standing Enclosure | ||
IP Rating IP65 | ||
Construction Sealed Top and Bottom Part Assembled with Side Parts | ||
Series PanelSeT | ||
Door Type Transparent | ||
Body Material Fibreglass Double Reinforced Polyester | ||
Colour Grey | ||
External Width 1.25m | ||
External Depth 420mm | ||
External Height 750mm | ||
NEMA Rating NEMA 1, NEMA 2, NEMA 13, NEMA 12 | ||
Colour RAL RAL 7035 | ||
Standards/Approvals UL 508 A, IEC 62208, UL/cUL, DNV Marine Veritas | ||
IK Rating IK08 | ||
- COO (Country of Origin):
- ES
The Schneider Electric Floor-standing polyester enclosure with a glazed door, offering protection against dust and water. Made from fiberglass-reinforced polyester, it ensures high electrical insulation and impact resistance for durability. Its transparent door opens 120° and features a two-point lock, making it ideal for industrial applications.
IP65 and IK08 protection
Class II insulation
RoHS and REACH compliant
