Weidmüller TRZ Series Interface Relay, DIN Rail, 230V Coil, DPDT, 45mA
- RS 제품 번호:
- 892-8874
- Distrelec 제품 번호:
- 300-94-805
- 제조사 부품 번호:
- 1123700000
- 제조업체:
- Weidmüller
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
- RS 제품 번호:
- 892-8874
- Distrelec 제품 번호:
- 300-94-805
- 제조사 부품 번호:
- 1123700000
- 제조업체:
- Weidmüller
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Weidmüller | |
| Product Type | Interface Relay | |
| Coil Voltage | 230V | |
| Contact Configuration | DPDT | |
| Mount Type | DIN Rail | |
| Series | TRZ | |
| Terminal Type | Spring Clamp | |
| Switching Current | 100mA | |
| Minimum Operating Temperature | -40°C | |
| Coil Current | 45mA | |
| Switching DC Voltage | 250V dc | |
| Switching AC Voltage | 250V ac | |
| Contact Material | Silver Alloy | |
| Maximum Operating Temperature | 60°C | |
| Width | 12.8mm | |
| Standards/Approvals | EN 61000-6-4, EN 61000-6-2, EN 61000-6-1, EN 55011, EN 50178 | |
| Height | 88mm | |
| Length | 90mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Weidmüller | ||
Product Type Interface Relay | ||
Coil Voltage 230V | ||
Contact Configuration DPDT | ||
Mount Type DIN Rail | ||
Series TRZ | ||
Terminal Type Spring Clamp | ||
Switching Current 100mA | ||
Minimum Operating Temperature -40°C | ||
Coil Current 45mA | ||
Switching DC Voltage 250V dc | ||
Switching AC Voltage 250V ac | ||
Contact Material Silver Alloy | ||
Maximum Operating Temperature 60°C | ||
Width 12.8mm | ||
Standards/Approvals EN 61000-6-4, EN 61000-6-2, EN 61000-6-1, EN 55011, EN 50178 | ||
Height 88mm | ||
Length 90mm | ||
제외
- COO (Country of Origin):
- CN
Weidmuller TERMSERIES Relay Modules
TERMSERIES complete relays modules consisting of a relay and base with AC/DC/UC coils, available in different versions:
With screw and tension-clamp connection
AgNi contact, optionally with hard gold-plated contacts
1 and 2 COs
Optionally with multiple-voltage input: 24...230 V UC
With various protective circuits in the input (free-wheel diode, RC element)
Illuminated ejection lever
