4D Systems SK-pixxiLCD-20P2-CTP-CLB, pixxiLCD-20 2in Capacitive Touch Screen Starter Kit
- RS 제품 번호:
- 204-2736
- 제조사 부품 번호:
- SK-pixxiLCD-20P2-CTP-CLB
- 제조업체:
- 4D Systems
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
- RS 제품 번호:
- 204-2736
- 제조사 부품 번호:
- SK-pixxiLCD-20P2-CTP-CLB
- 제조업체:
- 4D Systems
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | 4D Systems | |
| Diagonal Display Size | 2in | |
| Display Technology | Capacitive Touch Screen | |
| Kit Classification | Starter Kit | |
| Kit Name | pixxiLCD-20 | |
| 모두 선택 | ||
|---|---|---|
브랜드 4D Systems | ||
Diagonal Display Size 2in | ||
Display Technology Capacitive Touch Screen | ||
Kit Classification Starter Kit | ||
Kit Name pixxiLCD-20 | ||
- COO (Country of Origin):
- AU
The 4D Systems pixxiLCD series 2 inch intelligent display starter kit with PIXXI-28 graphics controller. The kit includes 1 x pixxiLCD-20P2, 1 x GEN4-IB,1 x 30-to-15-way 75 mm FFC cable, 1 x 4D-UPA, 1 x 5 pin ribbon cable and 1 x uSD-4GB-industrial
Low cost
Capacitive touch
Suitable for fast and easy integration
RoHS, REACH and CE compliant
Capacitive touch
Suitable for fast and easy integration
RoHS, REACH and CE compliant
Resolution 176 x 220
Brightness 460 cd/m2
Controller PIXXI-28
Storage Temperature -30°C to +80°C
Connector 15 way ZIF Socket
Display Viewing Area (mm) 31.68 x 39.60
Module Dimensions (mm) 44.60 x 65.80 x 7.00
Supply Voltage 5.0 VDC
Colours RGB 65K
Brightness 460 cd/m2
Controller PIXXI-28
Storage Temperature -30°C to +80°C
Connector 15 way ZIF Socket
Display Viewing Area (mm) 31.68 x 39.60
Module Dimensions (mm) 44.60 x 65.80 x 7.00
Supply Voltage 5.0 VDC
Colours RGB 65K
