Italtronic Enclosure 35.0814000.RCM for Raspberry Pi Compute Module, Grey

본 제품군 열람하기
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
RS 제품 번호:
256-4993
제조사 부품 번호:
35.0814000.RCM
제조업체:
Italtronic
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Italtronic

Product Type

Enclosure

For Use With

Raspberry Pi Compute Module

Colour

Grey

External Width

142mm

Body Material

ABS

External Depth

32.2mm

External Height

90mm

Standards/Approvals

RoHS

COO (Country of Origin):
IT

Italtronic DIN Rail Enclosure for Raspberry pi compute module, 8MCompact Modulbox XTS


The Italtronic kit enclosure modulebox XTS compact 8m raspberry pi cm modular enclosure can be fastened to DIN (EN 60715) rail and can be provided with several terminal covers. There are several versions of this modular enclosure which are type A which is similar to the previous modulebox product and bearing the same compatibility with the PCB type B with one side higher to leave more space for larger electronic components and type C with both sides higher to have more space for the electronic components.

Material used is self extinguishing blend PC/ABS

Colour is grey
