Amphenol ICC CD 26 Way Right Angle 2.285 mm Pitch D-Sub Connector, with Screw Female

본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.

모든 D Sub Connectors 열람하기
대량 구매 할인 기용 가능

Subtotal (1 unit)*

₩6,692.80

Add to Basket
수량 선택 또는 입력
단종되는 중
  • 최종적인 264 개 unit(s)이 배송 준비 됨
수량
한팩당
1 - 24₩6,692.80
25 - 49₩6,542.40
50 +₩6,410.80

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
137-2706
제조사 부품 번호:
ICD26S13E4GV00LF
제조업체:
Amphenol ICC
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Amphenol ICC

Number of Contacts

26

Product Type

D-Sub Connector

Orientation

Right Angle

Current

3A

Connector Gender

Female

Connector Type D

High Density

D-Sub Shell Size

A

Mounting Hardware

Screw

Housing Material

Thermoplastic

Voltage

300 V

Termination Type

Solder

Minimum Operating Temperature

-55°C

Contact Gender

Female

Maximum Operating Temperature

125°C

Standards/Approvals

No

Series

CD

Contact Plating

Tin, Nickel, Gold

Contact Material

Copper Alloy

Pitch

2.285mm

COO (Country of Origin):
IN
The new High Density D-Subminiature range is part of FCI’s I/O-Connections portfolio which provides customers access to a wide range of industry standard and application specific I/O interconnect solutions. FCI’s I/O connector solutions complete your board and system designs by providing high-density and high-speed interfaces to enable interconnect technologies for networking, storage and memory and complementary products for power distribution. Our range of standardized I/O solutions enables full compliance to industry standards, such as Ethernet, SFF, Infiniband, USB, PCMCIA or HDMI. FCI also has the capability to provide customized I/Osolutions optimized to address application specific requirements

Compact-D is the answer to increasing need for higher density packaging

Contact layout 15 to 78 positions available

Selected layouts are also available in Press-fit & Pin-in-Paste version

Comes with different PCB mounting and panel mounting accessory options

RoHS compliant
