Norcomp 380 15 Way Straight 1.27 mm Pitch Through Hole D-Sub Connector Female

모든 D Sub Connectors 열람하기
대량 구매 할인 기용 가능

Subtotal (1 unit)*

₩22,014.80

Add to Basket
수량 선택 또는 입력
재고있음
  • 1 개 단위 배송 준비 완료
  • 추가로 다른 지역에서 11 개 단위 배송 준비 완료
  • 추가로 2026년 4월 29일 부터 83 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량
한팩당
1 - 24₩22,014.80
25 - 49₩21,638.80
50 - 249₩21,074.80
250 - 499₩20,529.60
500 +₩20,022.00

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
135-4271
제조사 부품 번호:
380-015-213L001
제조업체:
Norcomp
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Norcomp

Product Type

D-Sub Connector

Number of Contacts

15

Orientation

Straight

Current

1A

Mount Type

Through Hole

Connector Gender

Female

Connector Type D

Micro-D

Housing Material

Polybutylene Terephthalate

Voltage

500.0 V

Termination Type

Solder

Minimum Operating Temperature

-55°C

Maximum Operating Temperature

85°C

Contact Gender

Female

Standards/Approvals

No

Contact Plating

Gold

Series

380

Contact Material

Brass

Pitch

1.27mm

COO (Country of Origin):
TW

NorComp MICRO-D 380 and 381 Series Micro Miniature D-Sub Connectors


MICRO-D 380 and 381 series PCB mount micro-miniature D-Sub connectors with a 1.27mm pitch and a compact design. The micro-miniature D-Sub connector is 1/3 the size of a standard D-Sub connector. These 380 series MICRO-D d-sub connectors have a metal to metal interface for improved grounding and shielding and a robust mechanical connection. The right angle versions of these micro-miniature D-Sub connectors feature boardlocks for extra retention on the PCB and 2.56 female screwlocks for a secure mounting connection. These MICRO-D D-Sub connectors are available in industry standard sizes of 9, 15 and 25 positions and intermate with most commercial competitive products.

Features and Benefits


• Compact space saving design, 1/3 size of standard D-Sub connectors

• Metal to metal interface for improved grounding and shielding

• Boardlocks (R/A versions) for extra PCB retention

• Screwlocks (R/A versions) for secure mounting

• 1 A contact rating

• Intermate with most commercial competitive products

Product Application Information


These MICRO-D series micro-miniature D-Sub connectors are ideal for use in commercial applications where a robust I/O connector is required and space is limited.
