KEMET 67 μH 8 A Common Mode Choke 22.2 mΩ
- RS 제품 번호:
- 183-6621
- 제조사 부품 번호:
- SHBC14-1R2A0067V
- 제조업체:
- KEMET
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
- RS 제품 번호:
- 183-6621
- 제조사 부품 번호:
- SHBC14-1R2A0067V
- 제조업체:
- KEMET
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | KEMET | |
| Inductance | 67μH | |
| Product Type | Common Mode Choke | |
| Maximum DC Current | 8A | |
| Series | SHBC | |
| Core Material | Fe-Si-Al Dust | |
| Test Frequency | 100kHz | |
| Packaging | Tray | |
| Maximum Operating Temperature | 125°C | |
| Minimum Operating Temperature | -40°C | |
| Number of Lines | 2 | |
| Automotive Standard | No | |
| Mount Type | Through Hole | |
| Inductance Tolerance | ±20 % | |
| Standards/Approvals | RoHS | |
| Depth | 17.1mm | |
| Maximum DC Resistance | 22.2mΩ | |
| Termination Style | Solder Pad | |
| Height | 33.5mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 KEMET | ||
Inductance 67μH | ||
Product Type Common Mode Choke | ||
Maximum DC Current 8A | ||
Series SHBC | ||
Core Material Fe-Si-Al Dust | ||
Test Frequency 100kHz | ||
Packaging Tray | ||
Maximum Operating Temperature 125°C | ||
Minimum Operating Temperature -40°C | ||
Number of Lines 2 | ||
Automotive Standard No | ||
Mount Type Through Hole | ||
Inductance Tolerance ±20 % | ||
Standards/Approvals RoHS | ||
Depth 17.1mm | ||
Maximum DC Resistance 22.2mΩ | ||
Termination Style Solder Pad | ||
Height 33.5mm | ||
- COO (Country of Origin):
- VN
The KEMET SHBC coils are normal mode chokes with a wide variety of characteristics. These coils are designed with Fe-Si-Al dust cores and are useful in various fields such as DC/DC converters as well as normal noise countermeasures.
Fe-Si-Al dust core material
Available for smoothing and converting
Low core loss
High frequency drive
Wide variety of sizes and specifications
Operating temperature range from −40°C to +125°C
Applications
Switching power supply outlet
DC-DC converter
Phase compensation
Boost converter
