STMicroelectronics STEVAL-CCA044V1 Dual BTL Class-D Audio Amplifier Demonstration Board Audio Amplifier Demonstration

모든 Analogue Development Tools 열람하기
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
RS 제품 번호:
196-2543
제조사 부품 번호:
STEVAL-CCA044V1
제조업체:
STMicroelectronics
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

STMicroelectronics

Analogue Function

Audio Amplifier

Product Type

Analogue Development Kit

Kit Classification

Demonstration Board

For Use With

160 W+160 W Dual BTL Class-D Audio Amplifier

Featured Device

TDA7498E

Kit Name

Dual BTL Class-D Audio Amplifier Demonstration Board

Standards/Approvals

RoHS Compliant

COO (Country of Origin):
IT
The STEVAL-CCA044V1 demonstration board is

designed for the TDA7498E high power dual BTL

class-D audio amplifier.

Thanks to its high efficiency, the device

assembled in the PSSO36 (slug-down) package

is capable of dissipating heat without a heatsink.

Jumpers on the board allow the configuration of

the amplifier in order to verify all the features as

single-ended or differential input, fixed gain

settings.

Microswitches are also provided to enable the

standby and mute functions.
