Proximity Sensors

Proximity sensors are designed to detect the presence and proximity of an object in range without any physical contact, using sound, light, infrared or electromagnetic fields instead. You can learn more in our complete guide to proximity sensors.


Types of Proximity Sensor

  • Inductive -  An inductive sensor provides non-contact detection of metallic objects. Some sensors can target both ferrous and non-ferrous metals, while others specialise in sensing only one type



  • Ultrasonic -  Ultrasonic sensors work by emitting a short burst of ultrasonic sound at a specific frequency towards the target. When the target reflects the sound back to the sensor, the sensor measures the time it takes for the echo to return. The sensor will use the time it takes the soundwave to travel back to calculate the distance between the sensor and the object.



  • Capacitive - Capacitive sensors can detect metallic and non-metallic materials. They can detect and measure materials that are conductive or have a greater dielectric constant than air using an electrical field



  • Infrared - Infrared sensors measure light with a wavelength in the IR spectrum (>700nm). They are not good at detecting visible light. IR sensors can recognise light from either external or built-in light sources.




...
Read more Read less

검색 필터링

총 4423개 제품 중 41번째-60번째 제품을 조회 중
한장내 검색 결과 수
제품설명 단가 Body Style Sensor Technology Thread Size Output Type Detection Range Terminal Type Series Supply Voltage Communication Protocol Length Width Depth Maximum DC Voltage Mounting Type
RS 제품 번호 831-3676
제조사 부품 번호NBN4-12GM35-A2-V1
제조사Pepperl + Fuchs
₩90,103.05
Each
수량
Barrel Inductive M12 x 1 PNP 4 mm M12 - 4 Pin - 10 → 30 V dc - 45mm - - 30V Non Flush
RS 제품 번호 804-9426
제조사 부품 번호E2A-S08KS02-M1-B2
제조사Omron
₩130,017.10
Each
수량
Barrel Inductive M8 x 1 PNP 2 mm M12 - 4 Pin - 12 → 24 V dc - 27mm - - 32V Flush Mount
RS 제품 번호 404-865
제조사 부품 번호E2AS12LS04WPB12M
제조사Omron
₩78,873.30
Each
수량
Barrel Inductive M12 x 1 PNP-NO 4 mm Cable - 12 → 24 V dc - 56mm - - 32V Flush Mount
RS 제품 번호 695-6732
제조사 부품 번호XS130B3PAL2
₩136,361.25
Each
수량
Barrel Inductive M30 x 1.5 PNP-NO 15 mm Cable OsiSense XS 12 → 24 V dc - 43mm - - 36V Flush Mount
RS 제품 번호 785-8452
제조사 부품 번호E2E-S05N03-WC-C1 2M
제조사Omron
₩130,017.10
Each
수량
Barrel Inductive M5 x 0.5 NPN-NO 3 mm Cable - 10 → 30 V dc - 31mm - - 30V Non Flush
RS 제품 번호 816-3663
제조사 부품 번호XSAV01801
₩232,696.85
Each
수량
Barrel Inductive M30 x 1.5 - 10 mm Cable - 24 → 210 V dc, 24 → 240 V ac - 81mm - - - Flush Mount
RS 제품 번호 280-6658
제조사 부품 번호UB2000-30GM-E5-V15
제조사Pepperl + Fuchs
₩376,036.20
Each
수량
Barrel Ultrasonic M30 x 1.5 PNP-NO/NC 80 → 2000 mm M12 - 5 Pin - 10 → 30 V dc - 94mm - - 30V -
RS 제품 번호 793-1807
제조사 부품 번호XS7C4A1MPG13
₩125,891.00
Each
수량
Block Inductive - - 15 mm PG13.5 Gland - 24 → 240 V ac/dc - 40mm 40mm 117mm 240V Flush Mount
RS 제품 번호 328-1410
제조사 부품 번호RJ15-14-N
제조사Pepperl + Fuchs
₩162,004.45
Each
수량
Ring Inductive - NAMUR 20 mm Cable - 5 → 25 V dc - 32.5mm 25mm 20mm 25V -
RS 제품 번호 506-2750
제조사 부품 번호3RG6233-3AB00-PF
제조사Pepperl + Fuchs
₩461,216.45
Each
수량
Barrel - M18 x 1 PNP 150 → 1000 mm 4-Pin M12 Connector - 12 → 30 V dc - 104mm - - 30V -
RS 제품 번호 701-8222
제조사RS PRO
₩65,098.45
Each
수량
Barrel Inductive M18 x 1 NPN-NO 5 mm Cable - 10 → 30 V dc - 48mm - - 30V Flush Mount
RS 제품 번호 816-3708
제조사 부품 번호XSDA400519H7
₩350,070.60
Each
수량
Block Inductive - - 40 mm Cable - 20 → 264 V ac - 100mm - - - Flush Mount
RS 제품 번호 258-4932
제조사 부품 번호UC2000-30GM-IUR2-V15
제조사Pepperl + Fuchs
₩676,864.85
Each
수량
Barrel Ultrasonic M30 x 1.5 Analogue 80 → 2000 mm M12 - 5 Pin - 10 → 30 V dc - 141.5mm - - 30V -
RS 제품 번호 444-3271
제조사 부품 번호XS612B1PAM12
₩139,182.25
Each
수량
Barrel Inductive M12 x 1 PNP-NO 4 mm M12 - 4 Pin - 12 → 48 V dc - 62mm - - 58V Flush Mount
RS 제품 번호 285-706
제조사 부품 번호IF5645
제조사ifm electronic
₩63,387.25
Each
수량
Barrel Inductive M12 x 1 PNP/NPN-NO/NC 2 mm Cable - 10 → 55 V dc - 71mm - - 55V Flush Mount
RS 제품 번호 203-7098
제조사 부품 번호UNDK 30P1703/S14
제조사Baumer
₩783,219.65
Each
수량
Block Ultrasonic - PNP-NO 100 → 1000 mm M12 Connector - 12 → 30 V dc - 65mm 30mm 31.1mm 30V -
RS 제품 번호 831-3593
제조사 부품 번호NBB5-18GM60-A0-V1
제조사Pepperl + Fuchs
₩165,278.05
Each
수량
Barrel Inductive M12 x 1 NPN 5 mm M12 - 4 Pin - 10 → 30 V dc - 70mm - - 30V Flush Mount
RS 제품 번호 285-712
제조사 부품 번호IG5594
제조사ifm electronic
₩59,341.75
Each
수량
Barrel Inductive M18 x 1 - 5 mm Cable - 10 → 55 V dc - 80mm - - 55V Flush Mount
RS 제품 번호 280-6686
제조사 부품 번호UB4000-30GM-E5-V15
제조사Pepperl + Fuchs
₩417,818.00
Each
수량
Barrel Ultrasonic M30 x 1.5 PNP-NO 200 → 4000 mm M12 - 5 Pin - 10 → 30 V dc - 108mm - - 30V -
RS 제품 번호 763-8318
제조사 부품 번호IFRM 12X9103
제조사Baumer
₩90,702.90
Each
수량
Barrel Inductive M12 x 1 NAMUR 4 mm Cable - 5 → 30 V dc - 34mm 12mm - 30V Non Flush
