Allen Bradley 700-SH Series Solid State Relay, 100 A Load, DIN Rail, Panel Mount, 530 V ac/dc Load, 48V ac/dc Control
- RS 제품 번호:
- 265-739
- 제조사 부품 번호:
- 700-SH100HA24
- 제조업체:
- Allen Bradley
Subtotal (1 unit)*
₩277,230.44
일시적 품절
- 2026년 8월 03일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩277,230.44 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 265-739
- 제조사 부품 번호:
- 700-SH100HA24
- 제조업체:
- Allen Bradley
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Allen Bradley | |
| Maximum Load Current | 100A | |
| Product Type | Solid State Relay | |
| Mount Type | DIN Rail, Panel | |
| Maximum Load Voltage | 530V ac/dc | |
| Minimum Load Voltage | 42V ac/dc | |
| Maximum Control Voltage | 48V ac/dc | |
| Minimum Control Voltage | 22V ac/dc | |
| Series | 700-SH | |
| Terminal Type | Screw | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | EN 61810-1, UR, CSA C22.2 No. 14, CSA, CE, cULus, cURus, UL508 | |
| Height | 28.8mm | |
| Width | 44.8 mm | |
| Length | 47.5mm | |
| Off State Leakage Current | 3mA | |
| Output Type | Relay | |
| 모두 선택 | ||
|---|---|---|
브랜드 Allen Bradley | ||
Maximum Load Current 100A | ||
Product Type Solid State Relay | ||
Mount Type DIN Rail, Panel | ||
Maximum Load Voltage 530V ac/dc | ||
Minimum Load Voltage 42V ac/dc | ||
Maximum Control Voltage 48V ac/dc | ||
Minimum Control Voltage 22V ac/dc | ||
Series 700-SH | ||
Terminal Type Screw | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals EN 61810-1, UR, CSA C22.2 No. 14, CSA, CE, cULus, cURus, UL508 | ||
Height 28.8mm | ||
Width 44.8 mm | ||
Length 47.5mm | ||
Off State Leakage Current 3mA | ||
Output Type Relay | ||
- COO (Country of Origin):
- CN
The Allen Bradley Hockey Puck Relays are robust, high-performance solid-state relays designed for industrial applications requiring high load switching capabilities. These relays offer options for handling continuous load current with proper heatsinking.
100 A max continuous load current with appropriate heatsink
530V AC max load voltage options
20 to 280V AC and 22 to 48V DC control voltage options
LED indicator for input or logic ON or OFF status monitoring
Protective cover for added safety
