- RS 제품 번호:
- 180-9213
- 제조사 부품 번호:
- EZ365
- 제조업체:
- Martindale
단종
- RS 제품 번호:
- 180-9213
- 제조사 부품 번호:
- EZ365
- 제조업체:
- Martindale
참조 문서
제정법과 컴플라이언스
해당 안됨
- COO (Country of Origin):
- PH
제품 세부 사항
Martindale EZ365 Socket, Earth Loop & RCD Tester
The Martindale socket and earth loop tester, RCD tester detect 28 faulty conditions and voltage level indication. It has a nominal operating voltage rating of 230V and current rating of 32A. This is also used for trip testing 30mA RCDs. It shows how safe the earth wiring, checks for polarity swap at the incoming supply.
Features and Benefits
• Quick and easy testing of polarity, loop impedance and RCDs
• Red/green LED indication for fault
• Buzzer indication when electrical fault occurs
• Non-trip earth loop impedance test
• Incoming electrical supply polarity swap test
• Tough sculpted design for easy removal
• Earth loop threshold accuracy: ±(10% + 0.3:)
• Power consumption: <2.5W
• Operating temperature ranges between -10°C and 40°C
• Red/green LED indication for fault
• Buzzer indication when electrical fault occurs
• Non-trip earth loop impedance test
• Incoming electrical supply polarity swap test
• Tough sculpted design for easy removal
• Earth loop threshold accuracy: ±(10% + 0.3:)
• Power consumption: <2.5W
• Operating temperature ranges between -10°C and 40°C
Certifications
• EN 61010-1
사양
속성 | 값 |
---|---|
Current Rating | 13A |
Voltage | 230V ac |
Earth Loop Impedance Test | Yes |
Safety Category | CAT II 300 V |
Power Source | Mains |
Dimensions | 80 x 45 x 65mm |
Weight | 95g |
Height | 65mm |
Maximum Operating Temperature | +40°C |
Safety Category Voltage | 300V |
Safety Category Level | CAT II |
Length | 80mm |
Width | 45mm |
Minimum Operating Temperature | -10°C |
