Honeywell GKM Safety Interlock Switch, Keyed, Fibreglass Reinforced Polyethylene Terephthalate, Key
- RS 제품 번호:
- 147-483
- 제조사 부품 번호:
- GKMA13
- 제조업체:
- Honeywell
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
대량 구매 할인 기용 가능
Subtotal (1 unit)*
₩329,355.00
재고있음
- 2 개 단위 배송 준비 완료
- 추가로 2026년 5월 04일 부터 10 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 - 9 | ₩329,355.00 |
| 10 - 14 | ₩316,192.50 |
| 15 + | ₩302,991.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 147-483
- 제조사 부품 번호:
- GKMA13
- 제조업체:
- Honeywell
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Honeywell | |
| Product Type | Safety Interlock Switch | |
| Lock Style | Keyed | |
| Lock Type | Key | |
| Actuator Included | No | |
| Safety Contacts | NO, NC | |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate | |
| Series | GKM | |
| Contact AC Voltage | 240V ac | |
| Minimum Operating Temperature | -25°C | |
| Number of Auxiliary Contacts | 2 | |
| IP Rating | IP67, IP66 | |
| Contact DC Voltage | 250V dc | |
| Hazardous Area Certification | NO | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | DOC 141 (EN60947-1 and EN 60947-5-1), cULus, UL 508, CE | |
| Length | 69.4mm | |
| Number of Head Directions | 2 | |
| Depth | 16mm | |
| Width | 34mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Honeywell | ||
Product Type Safety Interlock Switch | ||
Lock Style Keyed | ||
Lock Type Key | ||
Actuator Included No | ||
Safety Contacts NO, NC | ||
Housing Material Fibreglass Reinforced Polyethylene Terephthalate | ||
Series GKM | ||
Contact AC Voltage 240V ac | ||
Minimum Operating Temperature -25°C | ||
Number of Auxiliary Contacts 2 | ||
IP Rating IP67, IP66 | ||
Contact DC Voltage 250V dc | ||
Hazardous Area Certification NO | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals DOC 141 (EN60947-1 and EN 60947-5-1), cULus, UL 508, CE | ||
Length 69.4mm | ||
Number of Head Directions 2 | ||
Depth 16mm | ||
Width 34mm | ||
GKM Series, Miniature
Stackable design allows side by side mounting in a compact form
Small door swing radius allows use down to 160mm
IP67 protection, suitable for wet applications
Operating temperature -25 °C → +85 °C
Dimensions: H70mm x W34mm x D16mm
Interlock Switch
Note
Actuator sold separately
Approvals
UL, CSA, CE
Standards
IEC/EN60947-5-1, EN1088, EN60504, UL508, CSA22-2-14, UL748C
