RS PRO PT100 Temperature Sensor, 6mm Dia, 50mm Long, 3 Wire, Probe, 200°C Max
- RS 재고 번호:
- 350-417
- 제조업체:
- RS PRO
Subtotal (1 unit)*
₩42,006.72
재고있음
- 22 개 단위 배송 준비 완료
- 추가로 2026년 1월 06일 부터 20 개 단위 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
단위당 | 한팩당 |
|---|---|
| 1 + | ₩42,006.72 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 재고 번호:
- 350-417
- 제조업체:
- RS PRO
사양
기술적 참조
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | RS PRO | |
| Sensor Type | PT100 | |
| Probe Length | 50mm | |
| Probe Diameter | 6mm | |
| Minimum Temperature Sensed | -50°C | |
| Maximum Temperature Sensed | +200°C | |
| 모두 선택 | ||
|---|---|---|
브랜드 RS PRO | ||
Sensor Type PT100 | ||
Probe Length 50mm | ||
Probe Diameter 6mm | ||
Minimum Temperature Sensed -50°C | ||
Maximum Temperature Sensed +200°C | ||
- COO (Country of Origin):
- TR
RS PRO Standard Bayonet Type PT100 Thermo Resistances Temperature Sensor, 6mm Diameter, 50mm Immersion Length
The RS PRO Standard Bayonet Type PT100 Thermo Resistances Temperature Sensor is designed for precise temperature measurement across various industrial applications. With a 6mm diameter and 50mm immersion length, it ensures accurate readings, making it an essential tool in environments requiring reliable temperature monitoring.
Features and Benefits
Max Operating Temperature 200°C: Suitable for high-temperature applications, ensuring versatility.
1/2 Inch Fitting Nut: Provides secure and easy installation.
Protection Tube AISI304 (DIN1.4301) Stainless Steel: Offers durability and resistance to corrosion.
Sensor Type DIN/EN60751: Ensures compliance with international standards for reliability.
Cable Type Silicone Plus Silicone: Enhances flexibility and temperature resistance.
1/2 Inch Fitting Nut: Provides secure and easy installation.
Protection Tube AISI304 (DIN1.4301) Stainless Steel: Offers durability and resistance to corrosion.
Sensor Type DIN/EN60751: Ensures compliance with international standards for reliability.
Cable Type Silicone Plus Silicone: Enhances flexibility and temperature resistance.
Applications
Machinery manufacturing
Panel manufacturing
Production and test equipment
Industrial control applications
Food industry
Chemical industry
Textile sector
Panel manufacturing
Production and test equipment
Industrial control applications
Food industry
Chemical industry
Textile sector
Additional Information
Sensor Type: PT100
Number Of Wires: 3
Termination Type: Bare Wire Tail
Process Connection: 6 mm Tube
Number Of Wires: 3
Termination Type: Bare Wire Tail
Process Connection: 6 mm Tube
Why RS PRO?
RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
