Jumo RTD Temperature Probe, 6mm Dia, 2 Wire, Class B +90°C Max

모든 RTD Sensors 열람하기

Subtotal (1 unit)*

₩146,649.40

Add to Basket
수량 선택 또는 입력
마지막 RS 재고
  • 최종적인 1 개 unit(s)이 배송 준비 됨
수량
한팩당
1 +₩146,649.40

* 참고 가격: 실제 구매가격과 다를 수 있습니다

RS 제품 번호:
279-553
제조사 부품 번호:
902520/22-573-1003-1/000
제조업체:
Jumo
제품 정보를 선택해 유사 제품을 찾기
모두 선택

브랜드

Jumo

Sensor Type

RTD

Probe Diameter

6mm

Minimum Temperature Sensed

-30°C

Maximum Temperature Sensed

+90°C

Number Of Wires

2

Accuracy

Class B

COO (Country of Origin):
DE
The Jumo Screw on resistance thermometer enables temperature measurements in many areas of air conditioning technology due to the temperature dependence of the electrical resistance of its built-in platinum sensor and the special housing design. The housing with protection class IP65 is made of PC plastic and has an external sensor. The resistance thermometer is therefore preferably used for fast response temperature measurements in rooms and outdoors.

The resistance thermometer according to DIN EN 60751 (Class B) is designed as 1 x Pt100 in two-wire circuit
The transmitter is designed for temperatures from -30 to +90 °C
