ITW Switches H48M Series Illuminated Push Button Switch, Latching, Panel Mount, 19.56mm Cutout, SPDT, White LED, 250V
- RS 제품 번호:
- 122-2949
- 제조사 부품 번호:
- H48M-213W4044
- 제조업체:
- ITW Switches
일시 품절-다음 입고 날짜는 08/05/2024 (일/월/년) 이며, 그 후 5-10영업일내 홍콩에서 발송. 정확한 입고 수량에 대한 문의는 krenquiry@rs-components.com 로 연락주세요.
추가완료!
단가 개당
₩48,348.947
수량 | 한팩당 |
1 - 12 | ₩48,348.947 |
13 - 24 | ₩47,138.067 |
25 + | ₩46,413.609 |
- RS 제품 번호:
- 122-2949
- 제조사 부품 번호:
- H48M-213W4044
- 제조업체:
- ITW Switches
제정법과 컴플라이언스
- COO (Country of Origin):
- TW
제품 세부 사항
ITW H48M Series Stainless Steel Indicator
The ITW H48M Series of rugged stainless steel electromechanical pushbuttons are offered in both momentary & latching operation. The H48M series also offers spot & ring illumination options, to accompany the standard plain actuator. The series provides a reliable and robust switch solution to a wide range of applications, such as security, food processing & medical installations.
The H48M series have been designed to easily mount into panels of a thickness range of 0.5 mm to 4.5 mm. Frontal sealing offers IP67 rating and is achieved by an o-ring fitted around the body.
The H48M series have been designed to easily mount into panels of a thickness range of 0.5 mm to 4.5 mm. Frontal sealing offers IP67 rating and is achieved by an o-ring fitted around the body.
Features and Benefits
Electro-mechanical operation.
Premium stainless steel constructed housing.
Momentary or latching operation.
Panel sealing up to IP67 rating.
Plain, centre spot & ring illumination options.
LED options available.
Typical Applications include:
External control equipment.
Industrial machinery.
Security equipment.
Medical equipment.
Food processing.
Mass transit and lift trucks.
Electro-mechanical operation.
Premium stainless steel constructed housing.
Momentary or latching operation.
Panel sealing up to IP67 rating.
Plain, centre spot & ring illumination options.
LED options available.
Typical Applications include:
External control equipment.
Industrial machinery.
Security equipment.
Medical equipment.
Food processing.
Mass transit and lift trucks.
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
사양
속성 | 값 |
---|---|
Switch Operation | Latching |
Illuminated | Yes |
Panel Cut Out Diameter | 19.56mm |
Mounting Type | Panel Mount |
Push Button Colour | White |
Contact Configuration | SPDT |
Voltage Rating | 250V ac |
Push Button Style | Round |
LED Colour | White |
IP Rating | IP67 |
Series | H48M |
Contact Current Rating | 10 A |
Contact Material | Silver |
Contact AC Voltage Rating | 250V |
Legend | Standby Symbol |
Contact DC Voltage Rating | 28V |
Case Colour | Stainless Steel |
Manufacturer Part No. | H48M-213W4044 |
Operating Temperature Range | -25 → +65°C |
Maximum Operating Temperature | +65°C |
Terminal Type | Solder |
Minimum Operating Temperature | -25°C |
