Eaton Inductive Threaded Barrel Proximity Sensor, M12, 2 mm Detection, NPN NO, 30 V
- RS 제품 번호:
- 240-121
- 제조사 부품 번호:
- 135818 E55CAL12T110
- 제조업체:
- Eaton
Subtotal (1 unit)*
₩77,174.00
일시적 품절
- 2026년 4월 07일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 |
|---|---|
| 1 + | ₩77,174.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 240-121
- 제조사 부품 번호:
- 135818 E55CAL12T110
- 제조업체:
- Eaton
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Eaton | |
| Thread Size | M12 | |
| Sensor Technology | Inductive | |
| Body Style | Threaded Barrel | |
| Detection Range | 2 mm | |
| Output Function | NO | |
| Digital Switching Output Type | NPN | |
| Cable Length | 2m | |
| Connection Type | Pre-Cabled | |
| Supply Voltage | 30 V | |
| Length | 55mm | |
| IP Rating | IP66 | |
| Mounting Type | Flush | |
| Shielding | Unshielded | |
| Switching Frequency | 2 kHz | |
| Switching Current | 200 mA | |
| 모두 선택 | ||
|---|---|---|
브랜드 Eaton | ||
Thread Size M12 | ||
Sensor Technology Inductive | ||
Body Style Threaded Barrel | ||
Detection Range 2 mm | ||
Output Function NO | ||
Digital Switching Output Type NPN | ||
Cable Length 2m | ||
Connection Type Pre-Cabled | ||
Supply Voltage 30 V | ||
Length 55mm | ||
IP Rating IP66 | ||
Mounting Type Flush | ||
Shielding Unshielded | ||
Switching Frequency 2 kHz | ||
Switching Current 200 mA | ||
제외
- COO (Country of Origin):
- CN
The Eaton E55 Proximity Sensor is an advanced solution for reliable and efficient sensing in various industrial applications. This inductive sensor features a normally open contact design with a sensing distance of 2mm, ensuring precise detection of metal objects. With a robust plastic enclosure and IP66 protection, it is built to withstand harsh operating environments. Operating within a voltage range of 10 30VDC, it offers flexibility for integration into existing systems.
Utilises an inductive sensing technology for reliable metal detection
Incorporates a red LED for instant visual feedback of the switching state
Flexible voltage range enhances compatibility with various systems
Enables short circuit protection and prevents polarity reversal
Composed of insulated materials for improved safety
Incorporates a red LED for instant visual feedback of the switching state
Flexible voltage range enhances compatibility with various systems
Enables short circuit protection and prevents polarity reversal
Composed of insulated materials for improved safety
