Wurth Elektronik 5V 1 Output Surface Mount PCB Transformer
- RS 제품 번호:
- 182-8761
- 제조사 부품 번호:
- 750316032
- 제조업체:
- Wurth Elektronik
일시 품절-다음 입고 날짜는 07/10/2024 (일/월/년) 이며, 그 후 5-10영업일내 홍콩에서 발송. 정확한 입고 수량에 대한 문의는 krenquiry@rs-components.com 로 연락주세요.
추가완료!
단가 개당가격(275개가 1릴안에)
₩5,964.704
| 수량 | 한팩당 | Per Reel* |
| 275 - 275 | ₩5,964.704 | ₩1,640,152.213 |
| 550 - 825 | ₩5,814.638 | ₩1,599,120.292 |
| 1100 + | ₩5,724.943 | ₩1,574,549.092 |
| *다른 단위에 대한 가격 표시 | ||
- RS 제품 번호:
- 182-8761
- 제조사 부품 번호:
- 750316032
- 제조업체:
- Wurth Elektronik
참조 문서
제정법과 컴플라이언스
- COO (Country of Origin):
- CN
제품 세부 사항
MID-PPTI Push-Pull Transformers for Texas Instruments
Small size
Surface mount
Low profile
Operating temp: -40°C to 125°C
Functional, supplementary or reinforced insulation
Applications
Isolated interface power supply for CAN, RS-485, RS-422, RS-232, SPI, I2C, lower-power LAN
Industrial automation
Process control
Medical equipment
PLC analog and digital I/O modules
Isolated gate driver power supplies
AC motor drives
Uninterruptible power supplies (UPS)
Solar inverters
Polyphase energy meters
Protection relays and IEDs
Surface mount
Low profile
Operating temp: -40°C to 125°C
Functional, supplementary or reinforced insulation
Applications
Isolated interface power supply for CAN, RS-485, RS-422, RS-232, SPI, I2C, lower-power LAN
Industrial automation
Process control
Medical equipment
PLC analog and digital I/O modules
Isolated gate driver power supplies
AC motor drives
Uninterruptible power supplies (UPS)
Solar inverters
Polyphase energy meters
Protection relays and IEDs
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
사양
속성 | 값 |
|---|---|
| Secondary Voltage Rating | 5V |
| Primary Voltage Rating | 3.3V dc |
| Number of Outputs | 1 |
| Length | 10.41mm |
| Width | 11.89mm |
| Depth | 12.32mm |
| Dimensions | 10.41 x 11.89 x 12.32mm |
| Mounting Type | Surface Mount |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Maximum Operating Frequency | 150kHz |
