Phoenix Contact PTA Series PCB Terminal Block, 13-Contact, 3.5 mm Pitch, PCB, 1 Row
- RS 제품 번호:
- 284-0656
- 제조사 부품 번호:
- 1989065
- 제조업체:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
₩433,810.00
일시적 품절
- 2026년 6월 02일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
수량 | 한팩당 | 한팩당* |
|---|---|---|
| 50 + | ₩8,676.20 | ₩433,810.00 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 284-0656
- 제조사 부품 번호:
- 1989065
- 제조업체:
- Phoenix Contact
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Phoenix Contact | |
| Number of Contacts | 13 | |
| Product Type | PCB Terminal Block | |
| Pitch | 3.5mm | |
| Number of Rows | 1 | |
| Current | 17.5A | |
| Mount Type | PCB | |
| Minimum Wire Size mm² | 0.14mm² | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 16 AWG | |
| Maximum Wire Size AWG | 26 AWG | |
| Colour | Green | |
| Wire Connection Method | Screw | |
| Voltage | 20 V | |
| Series | PTA | |
| Width | 45.5 mm | |
| Length | 11.2mm | |
| Standards/Approvals | WEEE, RoHS, cULus China RoHS | |
| Depth | 12.82mm | |
| 모두 선택 | ||
|---|---|---|
브랜드 Phoenix Contact | ||
Number of Contacts 13 | ||
Product Type PCB Terminal Block | ||
Pitch 3.5mm | ||
Number of Rows 1 | ||
Current 17.5A | ||
Mount Type PCB | ||
Minimum Wire Size mm² 0.14mm² | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 16 AWG | ||
Maximum Wire Size AWG 26 AWG | ||
Colour Green | ||
Wire Connection Method Screw | ||
Voltage 20 V | ||
Series PTA | ||
Width 45.5 mm | ||
Length 11.2mm | ||
Standards/Approvals WEEE, RoHS, cULus China RoHS | ||
Depth 12.82mm | ||
- COO (Country of Origin):
- IN
The Phoenix Contact PCB terminal block provides high capacity due to its rectangular terminal block space and allows the connection of two conductors. The latching on the side enables various numbers of positions to be combined.
Contact material copper alloy
Surface characteristics tin plated
