WAGO 250 Series PCB Connector, 10-Contact, 3.5 mm Pitch, 1 Row, 250-110/000-006
- RS 제품 번호:
- 225-028
- 제조사 부품 번호:
- 250-110/000-006
- 제조업체:
- WAGO
Subtotal (1 Box of 30 units)*
₩159,236.00
일시적 품절
- 2026년 4월 24일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩159,236.00 | ₩5,307.24 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 225-028
- 제조사 부품 번호:
- 250-110/000-006
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 10 | |
| Pitch | 3.5mm | |
| Current | 8A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.2mm² | |
| Connector Gender | Male | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 24 AWG | |
| Maximum Wire Size AWG | 16 AWG | |
| Colour | Blue | |
| Wire Connection Method | Push-in | |
| Voltage | 160 V | |
| Width | 36.5 mm | |
| Standards/Approvals | CSA C22.2, IEC/EN 60664-1, UL 1059 | |
| Depth | 12mm | |
| Series | 250 | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 10 | ||
Pitch 3.5mm | ||
Current 8A | ||
Number of Rows 1 | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.2mm² | ||
Connector Gender Male | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 24 AWG | ||
Maximum Wire Size AWG 16 AWG | ||
Colour Blue | ||
Wire Connection Method Push-in | ||
Voltage 160 V | ||
Width 36.5 mm | ||
Standards/Approvals CSA C22.2, IEC/EN 60664-1, UL 1059 | ||
Depth 12mm | ||
Series 250 | ||
- COO (Country of Origin):
- CH
The Wago PCB Terminal Block delivers cutting edge connectivity with a focus on ease of use and space efficiency. Designed with a 10 pole configuration and an innovative push in CAGE CLAMP technology, this terminal block accommodates solid and fine stranded conductors up to 1.5 mm², ensuring reliable electrical connections without fuss. Its 45° conductor entry angle promotes effortless installation, while compact dimensions make it ideal for high density PCB applications.
Compact design allows for efficient use of board space
Designed for easy insertion of both solid and fine stranded conductors
Compliance with RoHS standards ensures environmental safety
Multiple colour options available for customisation
Tested and certified to meet various industry standards ensuring quality
