Hirose A3 Series Straight Surface Mount Pin Header, 50 Contact(s), 2.0mm Pitch, 2 Row(s), Unshrouded
- RS 제품 번호:
- 779-2797P
- 제조사 부품 번호:
- A3-50PA-2SV(71)
- 제조업체:
- Hirose
대량 구매 할인 기용 가능
가격 개당(튜브에 담겨 공급됨)**
₩7,927.96
현재 시스템 에러로 재고 수량 확인이 불가합니다. krenquiry@rs-components.com 에 문의하시거나 잠시후에 다시 시도해주시기 바랍니다.
수량 | 한팩당 |
---|---|
125 - 495 | ₩7,927.96 |
500 - 1245 | ₩7,681.68 |
1250 - 2495 | ₩7,518.12 |
2500 + | ₩7,354.56 |
** 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 779-2797P
- 제조사 부품 번호:
- A3-50PA-2SV(71)
- 제조업체:
- Hirose
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
---|---|---|
브랜드 | Hirose | |
Series | A3 | |
Pitch | 2.0mm | |
Number of Contacts | 50 | |
Number of Rows | 2 | |
Body Orientation | Straight | |
Shrouded/Unshrouded | Unshrouded | |
Mounting Type | Surface Mount | |
Connector System | Wire to Board | |
Termination Method | Solder | |
Contact Plating | Gold | |
Contact Material | Brass | |
Current Rating | 2.0A | |
Mating Pin Length | 3.5mm | |
Voltage Rating | 200 V ac | |
모두 선택 | ||
---|---|---|
브랜드 Hirose | ||
Series A3 | ||
Pitch 2.0mm | ||
Number of Contacts 50 | ||
Number of Rows 2 | ||
Body Orientation Straight | ||
Shrouded/Unshrouded Unshrouded | ||
Mounting Type Surface Mount | ||
Connector System Wire to Board | ||
Termination Method Solder | ||
Contact Plating Gold | ||
Contact Material Brass | ||
Current Rating 2.0A | ||
Mating Pin Length 3.5mm | ||
Voltage Rating 200 V ac | ||
